A.1 Specifications of Red and Black Test Lines
Model
IT-E301/10A
IT-E301/30A
IT-E301/30A
IT-E301/60A
IT-E301/120A
IT-E301/240A
IT-E301/240A
IT-E301/360A
AWG
The Maxi-
mum Current
Value( A)

♦ Specifications of Red and Black Test Lines

♦ Fuse Replacement
ITECH provides you with optional red and black test lines, which are sold indi-
vidually and you can select for test. For specifications of ITECH test lines and
maximum current values, refer to the table below.
Specification
10A
30A
30A
60A
120A
240A
240A
360A
For maximum current of AWG copper wire, refer to table blow.
10 12 14
40 25 20
AWG ( American Wire Gage), it means X wire ( marked on the wire). The table
above lists current capacity of single wire at working temperature of 30°C. For refer-
ence only.
