ITech IT6500C Series Manual

Highpowered and programmable power supply
Hide thumbs Also See for IT6500C Series:
Table of Contents

Advertisement

Quick Links

Highpowered and
IT6500C/D Series Programming Guide
programmable
Power supply
Model: IT6512C/IT6513C/IT6514C/IT6515C/IT6516C/IT6517C/
IT6522C/IT6523C/IT6524C/IT6525C/IT6526C/IT6527C/
IT6532C/IT6533C/IT6534C/IT6535C/IT6536C/IT6537C
/IT6542C/IT6543C/IT6544C/IT6545C/IT6546C/IT6547C
/IT6552C/IT6553C/IT6554C/IT6555C/IT6556C/IT6557C
/IT6562C/IT6563C/IT6564C/IT6565C/IT6566C/IT6567C
/IT6572C/IT6573C/IT6574C/IT6575C/IT6576C/IT6577C
/IT6582C/IT6583C/IT6584C/IT6585C/IT6586C/IT6587C/
IT6592C/IT6593C/IT6594C/IT6595C/IT6596C/IT6597C/
IT6512D/IT6513D/IT6514D/IT6515D/IT6516D/IT6517D/
IT6522D/IT6523D/IT6524D/IT6525D/IT6526D/IT6527D/
IT6532D/IT6533D/IT6534D/IT6535D/IT6536D/IT6537D
/IT6542D/IT6543D/IT6544D/IT6545D/IT6546D/IT6547D
/IT6552D/IT6553D/IT6554D/IT6555D/IT6556D/IT6557D
/IT6562D/IT6563D/IT6564D/IT6565D/IT6566D/IT6567D
/IT6572D/IT6573D/IT6574D/IT6575D/IT6576D/IT6577D
/IT6582D/IT6583D/IT6584D/IT6585D/IT6586D/IT6587D/
IT6592D/IT6593D/IT6594D/IT6595D/IT6596D/IT6597D
Version: 2.1
Via Acquanera, 29
22100 Como
tel. 031.526.566 (r.a.) fax 031.507.984
info@calpower.it
www.calpower.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT6500C Series and is the answer not in the manual?

Questions and answers

Related Manuals for ITech IT6500C Series

Summary of Contents for ITech IT6500C Series

  • Page 1 Via Acquanera, 29 22100 Como tel. 031.526.566 (r.a.) fax 031.507.984 info@calpower.it www.calpower.it Highpowered and programmable Power supply IT6500C/D Series Programming Guide Model: IT6512C/IT6513C/IT6514C/IT6515C/IT6516C/IT6517C/ IT6522C/IT6523C/IT6524C/IT6525C/IT6526C/IT6527C/ IT6532C/IT6533C/IT6534C/IT6535C/IT6536C/IT6537C /IT6542C/IT6543C/IT6544C/IT6545C/IT6546C/IT6547C /IT6552C/IT6553C/IT6554C/IT6555C/IT6556C/IT6557C /IT6562C/IT6563C/IT6564C/IT6565C/IT6566C/IT6567C /IT6572C/IT6573C/IT6574C/IT6575C/IT6576C/IT6577C /IT6582C/IT6583C/IT6584C/IT6585C/IT6586C/IT6587C/ IT6592C/IT6593C/IT6594C/IT6595C/IT6596C/IT6597C/ IT6512D/IT6513D/IT6514D/IT6515D/IT6516D/IT6517D/ IT6522D/IT6523D/IT6524D/IT6525D/IT6526D/IT6527D/ IT6532D/IT6533D/IT6534D/IT6535D/IT6536D/IT6537D /IT6542D/IT6543D/IT6544D/IT6545D/IT6546D/IT6547D /IT6552D/IT6553D/IT6554D/IT6555D/IT6556D/IT6557D /IT6562D/IT6563D/IT6564D/IT6565D/IT6566D/IT6567D /IT6572D/IT6573D/IT6574D/IT6575D/IT6576D/IT6577D /IT6582D/IT6583D/IT6584D/IT6585D/IT6586D/IT6587D/ IT6592D/IT6593D/IT6594D/IT6595D/IT6596D/IT6597D Version: 2.1...
  • Page 2 Notices Warranty Safety Notices © Itech Electronic, Co., Ltd. 2018 The materials contained in this No part of this manual may be document are provided “ as is “, reproduced in any form or by any means and is subject to change, without (including electronic storage and prior notice, in future editions.

  • Page 3: Warranty

    Warranty ITECH warrants that the product will be free from defects in material and workmanship under normal use for a period of one (1) year from the date of delivery (except those described in the Limitation of Warranty below).

  • Page 4: Safety Precautions

    Failure to comply with these precautions or specific warnings elsewhere in this manual will constitute a default under safety standards of design, manufacture and intended use of the instrument. ITECH assumes no liability for the customer’s failure to comply with these precautions.

  • Page 5: Waste Electrical And Electronic Equiment (Weee) Directive

    With reference to the equipment classifications described in the Annex 1 of the WEEE Directive, this instrument is classified as a “ Monitoring and Control Instrument “. To return this unwanted instrument, contact your nearest ITECH office. Copyright© Itech Electronics Co., Ltd.

  • Page 6: Compliance Information

    Connection of the instrument to a test object may produce radiations beyond the specified limit. Use high-performance shielded interface cable to ensure conformity with the EMC standards listed above. Safety Standard IEC 61010-1:2010/ EN 61010-1:2010 Copyright© Itech Electronics Co., Ltd.

  • Page 7: Table Of Contents

    SYSTem:COMMunicate:LAN:MACaddress? ......................22 Chapter4 Display Related Command ......................23 DISPlay[:WINDow][:STATe] ..........................23 DISPlay[:WINDow]:TEXT[:DATA] .......................... 23 DISPlay[:WINDOW]:TEXT:CLEar ........................... 23 Chapter5 Trigger Command ........................... 25 TRIGger[:IMMediate] ............................25 TRIGger:SOURce ..............................25 Chapter6 Input Measuring Commands ......................26 Copyright© Itech Electronics Co., Ltd.
  • Page 8 [SOURce:]SENSe:RVERse:PROTect[:STATe] ......................47 Chapter8 DCR Command ..........................48 DCR[:STATe] ................................. 48 "DCR:DATA?", ..............................48 DCR:BATTery:CAPAcity[:LEVel] ..........................49 Chapter9 Load Related Command（IT6500C） ..................... 50 LOAD[:STATe]............................... 50 LOAD:SELection..............................50 LOAD:NUMBer[:EXTernal] ........................... 51 LOAD:CURRent[:LEVel][:IMMediate][:AMPLitude] ....................51 LOAD:CURRent:MINimum[:LEVel] ........................52 Copyright© Itech Electronics Co., Ltd.
  • Page 9 CARWave:ISO21848:Umaxdyn:TEST:PULSe[:STATe] ..................... 73 CARWave:ISO21848:MOMENTary:VOLTage:DROP[:STATe] ................... 74 CARWave:ISO21848:RESet[:STATe] ........................74 CARWave:ISO21848:RESet:VOLTage[:LEVel] ......................75 CARWave:ISO21848:STARtup:PROFile[:STATe] ..................... 75 CARWave:ISO16750:LOAD:DUMP[:STATe] ......................76 CARWave:ISO16750:LOAD:DUMP:TEST[:MODe]....................76 CARWave:ISO16750:LOAD:DUMP[:VOLTage]:UN[:LEVel] ..................77 CARWave:ISO16750:LOAD:DUMP[:VOLTage]:US[:LEVel] ..................77 CARWave:ISO16750:LOAD:DUMP[:TIMe]:TD[:LEVel] ................... 78 CARWave:ISO16750:LOAD:DUMP:VOLTage[:LEVel]....................78 CARWave:SAE[:TEST]:2B[:STATe] ......................... 79 CARWave:SAE[:TEST]:2B:VOLTage[:LEVel] ......................79 Copyright© Itech Electronics Co., Ltd.
  • Page 10 CALibrate:PROGram:VOLTage:LEVel........................99 CALibrate:PROGram:VOLTage[:DATA] ........................ 100 CALibrate:PROGram:CURRent:LEVel ........................100 CALibrate:PROGram:CURRent[:DATA] ........................ 100 CALibrate:EQUal:INPut:CURRent:LEVel ......................101 CALibrate:EQUal:INPut:CURRent[:DATA]......................101 CALibrate:EQUal:OUTPut:CURRent:LEVel ......................101 CALibrate:EQUal:OUTPut:CURRent[:DATA] ......................101 CALibrate:SUMMary:OUTPut:CURRent:LEVel ....................102 CALibrate:SUMMary:OUTPut:CURRent[:DATA] ....................102 CALibrate:SAVe ..............................102 CALibrate:INITialize ............................103 Copyright© Itech Electronics Co., Ltd. viii...
  • Page 11 *CLS .................................. 110 *ESE .................................. 110 *ESR? ................................111 *IDN? ................................111 *OPC ................................. 111 *PSC.................................. 112 *RST .................................. 112 *SRE <n> ................................112 *STB .................................. 113 *SAV ................................. 113 *RCL:................................. 114 *TST? ................................114 Copyright© Itech Electronics Co., Ltd.

  • Page 12: Quality Certification And Assurance

    Multiple commands in a message Multiple SCPI commands can be combined and sent as a single message with one message terminator. There are two important Copyright© Itech Electronics Co., Ltd.

  • Page 13: Environmental Conditions

    VOLTage:TRIGgered 17.5;:INITialize;*TRG OUTPut OFF;*RCL 2;OUTPut ONIT872X-3X SCPI Communication protocol 17 Case sensitivity Common commands and SCPI commands are not case sensitive. You can use upper or lower for example: *RST = *rst Copyright© Itech Electronics Co., Ltd.

  • Page 14: Regulatory Markings

    A response message consists of data in a specific SCPI format sent from the instrument to the controller. The instrument sends the message only when commanded by a program message called a "query." The next figure illustrates SCPI message structure: Copyright© Itech Electronics Co., Ltd.
  • Page 15  newline (<NL>),decimal 10 or hexadecimal 0X0A in ASCII.  end or identify (<END>)  both of the above (<NL><END>). In the examples of this guide, there is an assumed message terminator at the Copyright© Itech Electronics Co., Ltd.

  • Page 16: 1.4 Response Data Type

    The following example shows how a multiple response message is terminated: 0; 1; 1; 0; <RMT> Message exchange protocol Two rules summarize the message exchange protocol: Rule 1.You must always tell the IT6500 Series what to send to the computer. Copyright© Itech Electronics Co., Ltd.

  • Page 17: 1.5 Command Format

    It is used to separate key words of a command with the key words in next level. As shown below: APPL:SIN 455E3,1.15,0.0 In this example, APPLy command assigns a sine wave with frequency of 455 Copyright© Itech Electronics Co., Ltd.
  • Page 18 IEEE-488 EOI (End or Identify) information can be used as <NL> character to replace termination command string of <NL> character. It is acceptable to place one <NL> after a <Enter>. Termination of command string always resets current SCPI command path to root level. Copyright© Itech Electronics Co., Ltd.

  • Page 19: 1.6 Data Type

    "ON" or "1". In query of Boolean settings, the instrument will always return "0" or "1". Boolean Parameter are required by the following commands: DISPlay {OFF|0|ON|1}  ASCII string Parameter String Parameter may actually include all ASCII character sets. Character Copyright© Itech Electronics Co., Ltd.

  • Page 20: 1.7 Communication Interface

    IT6500C have five standard communication interfaces: RS232, USB, GPIB, LAN and CAN. The customer can choose any one according to his demands. Please refer to user manual for detailed introductions of the remote interface connections. Copyright© Itech Electronics Co., Ltd.

  • Page 21: Chapter2 Scpi Status Register

    This bit is set to 1 when any one status of enabled query status register changes. Output buffer available Bit ESB is set to 1 when the status of a enabled standard event status register changes OPER status enabled operation register Copyright© Itech Electronics Co., Ltd.
  • Page 22 SCPI status register changes,then this bit is set to1. The following chart is the Status register Structure of the power supply: Copyright© Itech Electronics Co., Ltd.

  • Page 23: Chapter3 Scpi Command Description

    This command edits the enable register value of query event. In query, the power supply will return a decimal number representing the binary weighted sum of the enable register. Command syntax STATus:QUEStionable:ENABle <NRf> Arguments <.NR1> 0～65535 Copyright© Itech Electronics Co., Ltd.

  • Page 24: Status:questionable:ptransition

    STATus:QUEStionable:PTRansition <NR1> Arguments 0~65535 Example STAT:QUES:PTR 2000 Query syntax STATus:QUEStionable:PTRansition? Returns: STATus:QUEStionable:NTRansition This command is used to edit the negative transition trigger register of query event. Command syntax STATus:QUEStionable:NTRansition <NR1> Arguments 0~65535 Example STAT:QUES:NTR 1000 Copyright© Itech Electronics Co., Ltd.

  • Page 25: Status:operation[:Event]

    This command can set the parameter of operation event enable register. Setting parameter can determine which bit value of operation event register is 1 and the bit will cause OPER of status byte register to be 1. Command syntax STATus:OPERation:ENABle <NR1> Arguments 0～65535 Copyright© Itech Electronics Co., Ltd.

  • Page 26: Status:operation:ptransition

    Query syntax STATus:OPERation:PTRansition? Returns <NR1> STATus:OPERation:NTRansition This command is used to edit the negative transition trigger register of operation event. Command syntax STATus:OPERation:NTRansition <NR1> Arguments 0～65535 Example STATus:OPERation:NTRansition 1000 Query syntax STATus: OPERation:NTRansition? Returns <NR1> Copyright© Itech Electronics Co., Ltd.

  • Page 27: System:beeper:immediate

    This command is used to query the current SCPI version. The returned parameter is a string like “YYYY.V “, in which the YYYY is the year of that version, V is the software version of that year. Command syntax SYST:VERS? Arguments None Copyright© Itech Electronics Co., Ltd.

  • Page 28: System:error

    This command is used to switch the instrument to local control mode(control from panel). In this mode ,all of keys on front panel is valid. Command syntax SYSTem:LOCal Arguments None Query syntax None Example SYST:LOC Copyright© Itech Electronics Co., Ltd.

  • Page 29: System:rwlock

    This command is used to select the communication interface. Arguments RS232|USB|GPIB|LAN Example SYST:COMM:SEL RS232 Query syntax SYSTem:COMMunicate:SELect? Returns RS232|USB|GPIB|LAN SYSTem:COMMunicate:GPIB:ADDRess This command is used to set the address of GPIB interface. Command syntax SYSTem:COMMunicate:GPIB[:SELF]:ADDRess <NR1> Arguments <1-30> Reset Value Query syntax SYSTem:COMMunicate:GPIB[:SELF]:ADDRess? Copyright© Itech Electronics Co., Ltd.

  • Page 30: System:communicate:serial:baudrate

    Query syntax SYSTem:COMMunicate:SERial:BAUDrate? Returns <NR1> SYSTem:COMMunicate:LAN:CURRent:ADDRess This command is used to set IP address of power supply. Command syntax SYSTem:COMMunicate:LAN:CURRent:ADDRess <STR> Arguments <STR> Unit None *RST 192.168.0.200 Example SYST:COMM:LAN:CURR:ADDR "192.168.0.200" Query syntax SYSTem:COMMunicate:LAN:CURRent:ADDRess? Returns <STR> Copyright© Itech Electronics Co., Ltd.

  • Page 31: System:communicate:lan:current:dgateway

    SYST:COMM:LAN:CURR:DGAT "192.168.0.1" Query syntax SYSTem:COMMunicate:LAN:CURRent:DGATeway? Returns <STR> SYSTem:COMMunicate:LAN:CURRent:SMASk This command is used to set the subnet mask of power supply. Command syntax SYSTem:COMMunicate:LAN:CURRent:SMASk Arguments <STR> Unit None *RST 255.255.255.0 Example SYST:COMM:LAN:CURR:SMAS "255.255.255.0" Query syntax SYSTem:COMMunicate:LAN:CURRent:SMASk? Copyright© Itech Electronics Co., Ltd.

  • Page 32: System:communicate:lan:dhcp[:State]

    Reset Value Example SYST:COMM:LAN:DHCP 1 Query syntax SYSTem:COMMunicate:LAN:DHCP[:STATe]? Returns SYSTem:COMMunicate:LAN:SOCKetport This command is used to set socket port of communication. Command syntax SYSTem:COMMunicate:LAN:SOCKetport <NR1> Arguments <NR1> Unit None *RST 值 30000 Query syntax SYSTem:COMMunicate:LAN:SOCKetport? Returns <NR1> Copyright© Itech Electronics Co., Ltd.

  • Page 33: System:communicate:lan:macaddress

    SCPI Command Description SYSTem:COMMunicate:LAN:MACaddress? This command is used to return the MAC address of LAN communication. Command syntax SYSTem:COMMunicate:LAN:MACaddress? Arguments <STR> Copyright© Itech Electronics Co., Ltd.

  • Page 34: Chapter4 Display Related Command

    This command is used to display a character string on point area. Command syntax DISPlay[:WINDow]:TEXT[:DATA] <NR1>,<str> Arguments <NR1>,<str> Example DISP:TEXT 1, “HELL0 “ Query syntax DISPlay[:WINDow]:TEXT[:DATA]? Returns <str> DISPlay[:WINDOW]:TEXT:CLEar This command is used to clean the screen. Command syntax DISPlay[:WINDOW]:TEXT:CLEar Copyright© Itech Electronics Co., Ltd.
  • Page 35 Display Related Command Arguments None Example DISP:TEXT:CLE Copyright© Itech Electronics Co., Ltd.

  • Page 36: Chapter5 Trigger Command

    This command is used to create a trigger signal. Command syntax TRIGger[:IMMediate] Arguments None TRIGger:SOURce This command is used to set the trigger source. Command syntax TRIGger:SOURce <MANUal|BUS|EXTernal> Arguments MANUal|BUS|EXTernal Query syntax TRIGger:SOURce? Returns <CRD> Copyright© Itech Electronics Co., Ltd.

  • Page 37: Chapter6 Input Measuring Commands

    This command is used to fetch the DC voltage value in buffer. Command syntax FETCh[:SCALar]:VOLTage[:DC]? Returns <NRf> Unit MEASure[:SCALar]:CURRent[:DC]? This command is used to enquire the latest DC current value. Command syntax MEASure[:SCALar]:CURRent[:DC]? Arguments None Returns <NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 38: Fetch[:Scalar]:Current[:Dc]

    Returns Unit Example MEASure:SCALar:POWer:DC? FETCh[:SCALar]:POWer[:DC]? This command is used to fetch the power value in buffer. Command syntax FETCh:POWer? Returns <NRf> FETCh? This command is used to fetch the measurements of voltage, current and power. Copyright© Itech Electronics Co., Ltd.

  • Page 39: Measure

    Input Measuring Commands Command syntax FETCh? Returns <NRf>,<NRf>,<NRf> MEASure? This command is used to enquire the latest measurements of voltage, current and power. Command syntax MEASure? Returns <NRf>,<NRf>,<NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 40: Chapter7 Output Commands

    0.5 (The reset value of different models are different) Example CURR 2.0 Query syntax [SOURce:]CURRent[:LEVel][:IMMediate][:AMPLitude]? [MINimum|MAXimum] Returns [SOURce:]CURRent:MINimum[:LEVel] This command is used to set the minimum value of current. Command syntax [SOURce:]CURRent:MINimum[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value Example CURR:MIN 0.0 Copyright© Itech Electronics Co., Ltd.

  • Page 41: [Source:]Current:maximum[:Level]

    Arguments MINimum|MAXimum|NRf Unit Reset Value MAXimum Example CURR:MAX 120.0 Query syntax [SOURce:]CURRent:MAXimum[:LEVel]? [MINimum|MAXimum] Returns Related Command CURR:MIN ,CURR [SOURce:]CURRent:RISE[:LEVel] This command is used to set rising time of current. Command syntax [SOURce:]CURRent:RISE[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Copyright© Itech Electronics Co., Ltd.

  • Page 42: [Source:]Current:fall[:Level]

    This command is used to set falling time of current. Command syntax [SOURce:]CURRent:FALL[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 0.001 Example CURR:FALL 2.0 Query syntax [SOURce:]CURRent:FALL[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]CURRent:PROTection:STATe This command is used to set over current protection state. Command syntax [SOURce:]CURRent:PROTection:STATe <bool> Copyright© Itech Electronics Co., Ltd.

  • Page 43: [Source:]Current:protection[:Level]

    Command syntax [SOURce:]CURRent:PROTection[:LEVel] <MINimum|MAXimum|DEFault|NRf> Arguments MINimum|MAXimum|DEFault|NRf Unit Reset Value MAXimum Example CURR:PROT 10.0 Query syntax [SOURce:]CURRent:PROTection[:LEVel]? [MINimum|MAXimum|DEFault] Returns [SOURce:]CURRent:PROTection:DELay This command is used to set delay time for over current protection. Command syntax [SOURce:]CURRent:PROTection:DELay <MINimum|MAXimum|NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 44: [Source:]Voltage[:Level][:Immediate][:Amplitude]

    This command is used to set output Voltage value. Command syntax [SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value Example VOLT 60.0 Query syntax [SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MINimum|MAXimum] Returns [SOURce:]VOLTage:MINimum[:LEVel] This command is used to set minimum value of voltage. Copyright© Itech Electronics Co., Ltd.

  • Page 45: [Source:]Voltage:maximum[:Level]

    VOLT:MIN 2.0 Query syntax [SOURce:]VOLTage:MINimum[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]VOLTage:MAXimum[:LEVel] This command is used to set maximum value of voltage. Command syntax [SOURce:]VOLTage:MAXimum[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value MAXimum Example VOLT:MAX 24.0 Query syntax [SOURce:]VOLTage:MAXimum[:LEVel]? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 46: [Source:]Voltage:rise[:Level]

    VOLT:RISE 5.0 Query syntax [SOURce:]VOLTage:RISE[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]VOLTage:FALL[:LEVel] This command is used to set falling time of voltage. Command syntax [SOURce:]VOLTage:FALL[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 0.001 Example VOLT:FALL 2.0 Query syntax [SOURce:]VOLTage:FALL[:LEVel]? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 47: [Source:]Voltage:protection:state

    Command syntax [SOURce:]VOLTage:PROTection[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value MAXimum Example VOLT:PROT MAX Query syntax [SOURce:]VOLTage:PROTection[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]VOLTage:PROTection:DELay This command is used to set delay time for over voltage protection. Command syntax [SOURce:]VOLTage:PROTection:DELay <MINimum|MAXimum|NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 48: [Source:]Power[:Level][:Immediate][:Amplitude]

    This command is used to set output power. Command syntax: [SOURce:]POWer[:LEVel][:IMMediate][:AMPLitude] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value MAXimum Example POW 5.0 Query syntax [SOURce:]POWer[:LEVel][:IMMediate][:AMPLitude]? [MINimum|MAXimum] Returns [SOURce:]POWer:MINimum[:LEVel] This command is used to set minimum value of power. Copyright© Itech Electronics Co., Ltd.

  • Page 49: [Source:]Power:maximum[:Level]

    POW:MIN 2.0 Query syntax [SOURce:]POWer:MINimum[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]POWer:MAXimum[:LEVel] This command is used to set maximum value of power. Command syntax [SOURce:]POWer:MAXimum[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value MAXimum Example POW:MAX min Query syntax [SOURce:]POWer:MAXimum[:LEVel]? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 50: [Source:]Power:rise[:Level]

    POW:RISE 5.0 Query syntax [SOURce:]POWer:RISE[:LEVel]? [MINimum|MAXimum] Returns [SOURce:]POWer:FALL[:LEVel] This command is used to set falling time of power. Command syntax [SOURce:]POWer:FALL[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 0.001 Example POW:FALL 3.0 Query syntax [SOURce:]POWer:FALL[:LEVel]? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 51: [Source:]Power:protection:state

    This command is used to set power value for over power protection. Command syntax [SOURce:]POWer:PROTection[:LEVel] <MINimum|MAXimum|DEFault|NRf> Arguments MINimum|MAXimum|DEFault|NRf Unit Query syntax [SOURce:]POWer:PROTection[:LEVel]? [MINimum|MAXimum|DEFault] Returns [SOURce:]POWer:PROTection:DELay This command is used to set delay time for over power protection. Command syntax [SOURce:]POWer:PROTection:DELay <MINimum|MAXimum|NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 52: [Source:]Resistance[:Level][:Immediate][:Amplitude]

    POW: PROT: DEL 2.0 Query syntax [SOURce:]POWer:PROTection:DELay? [MINimum|MAXimum] Returns [SOURce:]RESistance[:LEVel][:IMMediate][:AMPLitude This command is used to set internal resistance. Command syntax [SOURce:]RESistance[:LEVel][:IMMediate][:AMPLitude] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Ohms Reset Value MINimum Example RES 3.0 Query syntax [SOURce:]RESistance[:LEVel][:IMMediate][:AMPLitude]? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 53: [Source:]Protection:triggered

    This command is used to set output voltage and current. Command syntax [SOURce:]APPly <NRf+>,<NRf+> Arguments <MINimum|MAXimum|NRf >,< MINimum|MAXimum|NRf > Unit V, A Example APPL 12.0V,24.0A Query syntax [SOURce:]APPLy? Returns NRf,NRf [SOURce:]EXTern[:STATe] This command is used to set external control state. Copyright© Itech Electronics Co., Ltd.

  • Page 54: [Source:]Extern:monitor:range

    This command is used to set output range of external monitor. Command syntax [SOURce:]EXTern:MONitor:RANGe <10V|5V> Arguments 10V|5V Reset Value Example EXT:MON:RANG 5V Query syntax [SOURce:]EXTern:MONitor:RANGe? Returns 10V|5V [SOURce:]EXTern:PROGram:MODE This command is used to set external program mode. Command syntax [SOURce:]EXTern:PROGram:MODE <VOLTage| RESistance> Copyright© Itech Electronics Co., Ltd.

  • Page 55: [Source:]Extern:program:range

    This command is used to set external program range. Command syntax [SOURce:]EXTern:PROGram:RANGe <10V/10K|5V/5K> Arguments 10V/10K|5V/5K Reset Value 10V/10K Example EXT:PROG:RANG 10V/10K Query syntax [SOURce:]EXTern:PROGram:RANGe? Returns [SOURce:]EXTern:PROGram:RANGe? [SOURce:]OUTPut[:STATe] This command is used to control the output switch state. Command syntax [SOURce:]OUTPut[:STATe] <bool> Arguments 0|1|OFF|ON Copyright© Itech Electronics Co., Ltd.

  • Page 56: [Source:]Cv:priority

    This command is used to set the CV priority. Command syntax [SOURce:]CV:PRIority <HIGH|LOW> Arguments HIGH|LOW Reset Value HIGH Example CV:PRI HIGH Query syntax [SOURce:]CV:PRIority? Returns <CRD> [SOURce:]CC:PRIority This command is used to the CC priority. Command syntax [SOURce:]CC:PRIority <HIGH|LOW> Arguments HIGH|LOW Reset HIGH Copyright© Itech Electronics Co., Ltd.

  • Page 57: [Source:]Priority:type

    [SOURce:]PRIority:TYPE <CV|CC> Arguments CV|CC Reset Value Example PRI:TYPE CV Query syntax [SOURce:]PRIority:TYPE? Returns <CRD> [SOURce:]FILTer:LEVel This command is used to set level of filter. Command syntax [SOURce:]FILTer:LEVel <LOW|MEDium|FAST> Arguments LOW|MEDium|FAST Query syntax [SOURce:]FILTer:LEVel? Returns <CRD> Copyright© Itech Electronics Co., Ltd.

  • Page 58: [Source:]Sense:rverse:protect[:State]

    Output Commands [SOURce:]SENSe:RVERse:PROTect[:STATe] This command is used to set the status of sense reverse protection. Command syntax [SOURce:]SENSe:RVERse:PROTect[:STATe] <bool> Arguments 0|1|OFF|ON Query syntax [SOURce]SENSe:RVERse:PROTect[:STATe]? Returns <0|1> Copyright© Itech Electronics Co., Ltd.

  • Page 59: Chapter8 Dcr Command

    DCR[:STATe] <bool> Arguments 0|1|OFF|ON Reset Value Example DCR 0 Query syntax DCR[:STATe]? Return Arguments "DCR:DATA?", This command is used to query DCR value. Command syntax DCR:DATA? Arguments None Reset Value Example DCR:DATA? Return Arguments <NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 60: Dcr:battery:capacity[:Level]

    DCR Command DCR:BATTery:CAPAcity[:LEVel] This command is used to enter capacity of under test battery. Command syntax DCR:BATTery:CAPAcity <NRf> Arguments <NRf> Reset Value Example DCR:BATTery:CAPAcity 0.1 Query syntax DCR:BATTery:CAPAcity? Return Arguments <NRf> Copyright© Itech Electronics Co., Ltd.

  • Page 61: Chapter9 Load Related Command（It6500C

    IT6500D series models. LOAD[:STATe] This command is used to set load state. When the load of IT6500C Series power supply is on, you need to select internal load or external load. Default load is internal load. IT6500D Series power supply only has internal load. This command is used to turn on and off load function state.

  • Page 62: Load:number[:External]

    Query syntax LOAD:NUMBer[:EXTernal]? Returns LOAD:CURRent[:LEVel][:IMMediate][:AMPLitude] This command is used to set current of load. Command syntax LOAD:CURRent[:LEVel][:IMMediate][:AMPLitude] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 5 (The reset value of different models are different) Example LOAD:CURR 2.0 Copyright© Itech Electronics Co., Ltd.

  • Page 63: Load:current:minimum[:Level]

    Arguments MINimum|MAXimum|NRf Unit Reset Value Example LOAD:CURR:MIN 2.0 Query syntax LOAD:CURRent:MINimum[:LEVel]? [MINimum|MAXimum] Returns Related Command LOAD:CURR:MAX,LOAD:CURR LOAD:CURRent:MAXimum[:LEVel] This command is used to set maximum value of load current. Command syntax LOAD:CURRent:MAXimum[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Copyright© Itech Electronics Co., Ltd.

  • Page 64: Load:current:rise[:Level]

    Command syntax LOAD:CURRent:RISE[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 0.001 Example LOAD:CURR:RISE 4.0 Query syntax LOAD:CURRent:RISE[:LEVel]? [MINimum|MAXimum] Returns LOAD:CURRent:FALL[:LEVel] This command is used to set falling time for load current. Command syntax LOAD:CURRent:FALL[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Copyright© Itech Electronics Co., Ltd.

  • Page 65: Load:current:protection:state

    This command is used to set load OCP state. Command syntax LOAD:CURRent:PROTection:STATe <bool> Arguments ON|OFF|1|0 Reset Value Example LOAD:CURR:PROT:STAT 1 Query syntax LOAD:CURRent:PROTection:STATe? Returns LOAD:CURRent:PROTection[:LEVel] This command is used to set current value of load OCP. Command syntax LOAD:CURRent:PROTection[:LEVel] <MINimum|MAXimum|DEFault|NRf> Arguments MINimum|MAXimum|DEFault|NRf Copyright© Itech Electronics Co., Ltd.

  • Page 66: Load:current:protection:delay

    This command is used to set delay time for load OCP. Command syntax LOAD:CURRent:PROTection:DELay <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value Example LOAD:CURR:PROT:DEL 0.02 Query syntax LOAD:CURRent:PROTection:DELay? [MINimum|MAXimum] Returns LOAD:POWer[:LEVel][:IMMediate][:AMPLitude] This command is used to set the load power. Command syntax LOAD:POWer[:LEVel][:IMMediate][:AMPLitude] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Copyright© Itech Electronics Co., Ltd.

  • Page 67: Load:power:minimum[:Level]

    This command is used to set minimum power of load. Command syntax LOAD:POWer:MINimum[:LEVel] [MINimum|MAXimum|NRf] Arguments MINimum|MAXimum|NRf Unit Reset Value Example LOAD:POW:MIN 2.0 Query syntax LOAD:POWer:MINimum[:LEVel]? [MINimum|MAXimum] Returns Related Command LOAD:POW:MAX,LOAD:POW LOAD: POWer:MAXimum[:LEVel] This command is used to set maximum value of power. Copyright© Itech Electronics Co., Ltd.

  • Page 68: Load: Power:rise[:Level]

    LOAD:POWer:MAXimum[:LEVel]? [MINimum|MAXimum] Returns Related Command LOAD:POW:MIN,LOAD:POW LOAD: POWer:RISE[:LEVel] This command is used to set rising time for load power. Command syntax LOAD:POWer:RISE[:LEVel] <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value 0.001 Example LOAD:POWer:RISE[:LEVel] 200ms Query syntax LOAD:POWer:RISE[:LEVel]? [MINimum|MAXimum] Copyright© Itech Electronics Co., Ltd.

  • Page 69: Load:power:fall[:Level]

    Reset Value 0.001 Example LOAD:POW:FALL 0.2 Query syntax LOAD:POWer:FALL[:LEVel]? [MINimum|MAXimum] Returns LOAD:POWer:PROTection:STATe This command is used to set over power protect state. Command syntax LOAD:POWer:PROTection:STATe <bool> Arguments ON|OFF|1|0 Reset Value Example LOAD:POW:PROT:STAT 1 Query syntax [SOURce:]POWer:PROTection:STATe? Copyright© Itech Electronics Co., Ltd.

  • Page 70: Load:power:protection[:Level]

    Reset Value MAXimum Example LOAD:POW:PROT MAX Query syntax LOAD:POWer:PROTection[:LEVel]? [MINimum|MAXimum|DEFault] Returns LOAD:POWer:PROTection:DELay This command is used to set delay time for load OPP. Command syntax LOAD:POWer:PROTection:DELay <MINimum|MAXimum|NRf> Arguments MINimum|MAXimum|NRf Unit Reset Value Example LOAD:POW:PROT:DEL 0.04 Copyright© Itech Electronics Co., Ltd.
  • Page 71 Load Related Command（IT6500C） Query syntax LOAD:POWer:PROTection:DELay? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 72: Chapter10 List Operation Commands

    LIST[:STATe ]<bool> Arguments 0|1|OFF|ON Reset Value Example LIST:STAT 1 Query syntax LIST:STATe? Returns LIST:RECall This command is used to recall a list file. Command syntax LIST:RECall <MINimum|MAXimum|<1~10>> Arguments MINimum|MAXimum|<1~10> Example LIST:REC 1 Query syntax LIST:RECAll? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 73: List:edit

    Command syntax LIST:REPeat <MINimum|MAXimum|1~65535> Arguments MINimum|MAXimum|<1 to 65535> Example LIST:REP 2000 Query syntax LIST:REPeat? [MINimum|MAXimum] Returns LIST:SEQuence:COUNt This command is used to edit the wave count of list file. Command syntax LIST:SEQuence:COUNt <1-10> Arguments <1~10> Copyright© Itech Electronics Co., Ltd.

  • Page 74: List:sequence:select

    Query syntax LIST:SEQuence:SELect? <NR1> Returns LIST:SEQuence:REPeat This command is used to edit the running count of sequence which is linked to the List file. Command syntax LIST:SEQuence:REPeat <1~10>,<MINimum|MAXimum|<NR1> Arguments <1~10>,MINimum|MAXimum|<1~65535> Query syntax LIST:SEQuence:REPeat? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 75: List:save

    This command is used to save the list file in a nonvolatile memory. Command syntax LIST:SAVe <1~10> Arguments <1-10> Example LIST:SAV 4 LIST:PAUSe[:STATe] This command is used to pause the list and continue. Command syntax LIST:PAUSe[:STATe] <bool> Arguments 0|1|OFF|ON Example LIST:PAUS 0 Query syntax LIST:PAUSe[:STATe]? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 76: Chapter11 Wave Operation Command

    This command is used to recall a wave file. Command syntax SEQuence:RECall <NR1> Arguments MINimum|MAXimum|<1-100> Example SEQ:REC 1 Query syntax SEQ:REC? Returns SEQuence:STEP:COUNt This command is used to edit the step count of wave file. Command syntax SEQuence:STEP:COUNt <1~10> Copyright© Itech Electronics Co., Ltd.

  • Page 77: Sequence[:Step]:Voltage

    <1-10>,MINimum|MAXimum|NRf Unit Example SEQ:VOLT 6,7.0V Query syntax SEQuence[:STEP]:VOLTage？<NR1>,[MINimum|MAXimum] Returns SEQuence[:STEP]:CURRent This command is used to edit the current of specified step of a wave file. Command syntax SEQuence[:STEP]:CURRent <NR1>,<MINimum|MAXimum|NRf> Arguments <1~10>,MINimum|MAXimum|NRf Unit Example SEQ:CURR 1,12.0 Copyright© Itech Electronics Co., Ltd.

  • Page 78: Sequence[:Step]:Load:current

    SEQuence[:STEP]:LOAD:CURRent? <NR1> Returns <NRf> SEQuence[:STEP]:WIDTh This command is used to edit the width of specified step of the wavefile . Command syntax SEQuence[:STEP]:WIDth <NR1>,<MINimum|MAXimum|NRf> Arguments <1~10>,MINimum|MAXimum|NRf Unit Example SEQ:WIDT 1,64 Query syntax SEQuence[:STEP]:WIDTh? <NR1>,[MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 79: Sequence[:Step]:Slope

    Command syntax SEQuence[:STEP]:SLOPe <NR1>,MINimum|MAXimum|NRf Arguments <NR1>,MINimum|MAXimum|NRf Unit Example SEQ:SLOP 1,4 Query syntax SEQuence[:STEP]:SLOPe? <NR1>,[MINimum|MAXimum] Returns SEQuence:SAVe This command is used to save the wave file. Command syntax SEQuence:SAVe <NR1> Arguments <1~100> Example SEQ:SAV 1 Copyright© Itech Electronics Co., Ltd.

  • Page 80: Chapter12 Car Wave Command（It6500C

    CARW:ISO16750:SHOR 1 Query syntax CARWave:ISO16750:SHORt:DROP[:STATe]? Returns CARWave:ISO16750:SHORt:DROP:VOLTage[:LEVel] This command is used to select ISO analog voltage of short drop wave of car. Command syntax CARWave:ISO16750:SHORt:DROP:VOLTage <12V|24V> Arguments 12V|24V Reset Value Example CARW:ISO16750:SHOR:DROP:VOLT 24V Query syntax CARW:ISO16750:SHOR:DROP:VOLT? Copyright© Itech Electronics Co., Ltd.

  • Page 81: Carwave:iso16750:Reset[:State]

    CARWave:ISO16750:RESet:VOLTage[:LEVel] This command is used to set minimum supply voltage of ISO reset wave of car Command syntax CARWave:ISO16750:RESet:VOLTage <value> Arguments MINimum|MAXimum|NR3 Reset Value Example CARW:ISO16750:RES:VOLT 5.0 , CARW:ISO16750:RES:VOLT? MAX Query syntax CARWave:ISO16750:RESet:VOLTage? [MINimum|MAXimum] Returns Copyright© Itech Electronics Co., Ltd.

  • Page 82: Carwave:iso16570:Startup:profile[:State]

    This command is used to select ISO startup wave voltage of car. Command syntax CARWave:ISO16750:STRTtup:PROFile:VOLTage <12V|24V> Arguments 12V|24V Reset Value Example CARW:ISO16750:STAR:PROF:VOLT 12V Query syntax CARWave:ISO16750:STARtup:VOLTage? Returns <CRD> CARWave:ISO16750:STARtup:PROFile:INDex This command is used to select ISO startup wave level of car. Copyright© Itech Electronics Co., Ltd.

  • Page 83: Carwave:startup:din40839[:State]

    This command is used to analog DIN40839 startup wave of car. Command syntax CARWave:STARtup:DIN40839 <bool> Arguments 0|1|OFF|ON Reset Value Example CARW:STAR:DIN40839 1 Query syntax CARWave:STARtup:DIN40839? Returns CARWave:STARtup:DIN40839:VOLTage[:SELect] This command is used to select DIN40839 startup wave voltage of car. Command syntax CARWave:STARtup:DIN40839:VOLTage <12V|24V> Copyright© Itech Electronics Co., Ltd.

  • Page 84: Carwave:startup:din40839:Voltage:start:level

    This command is used to set user-defined DIN40839 start voltage level. Command syntax CARWave:STARtup:DIN40839:VOLTage:STARt:LEVel <Value> Arguments 12V|24V Reset Value Example CARW:STAR:DIN40839:VOLT:STAR:LEV Query syntax CARWave:STARtup:DIN40839:VOLTage:STARt:LEVe? Returns <CRD> CARWave:ISO21848:Umaxdyn:TEST:PULSe[:STATe] This command is used to in ISO21848Umaxdyn test pulse. Command syntax CARWave:ISO21848:Umaxdyn:TEST:PULSe[:STATe] 0|1 Arguments 0|1|ON|OFF Copyright© Itech Electronics Co., Ltd.

  • Page 85: Carwave:iso21848:Momentary:voltage:drop[:State]

    Command syntax CARWave:ISO21848:MOMENTary:VOLTage:DROP[:STATe] 0|1 Arguments 0|1|ON|OFF Reset Value Example CARWave:ISO21848:MOMENTary:VOLTage:DROP 1 Query syntax CARWave:ISO21848:MOMENTary:VOLTage:DROP[:STATe]? Returns <CRD> CARWave:ISO21848:RESet[:STATe] This command is used to analog ISO21848 reset wave of car. Command syntax CARWave:ISO21848:RESet[:STATe] <bool> Arguments ON|OFF|1|0 Reset Value Copyright© Itech Electronics Co., Ltd.

  • Page 86: Carwave:iso21848:Reset:voltage[:Level]

    Reset Value Example CARW:ISO21848:RES:VOLT 5.0 , CARW:ISO21848:RES:VOLT? MAX Query syntax CARWave:ISO21848:RESet:VOLTage[:LEVel]? [MINimum|MAXimum] Returns CARWave:ISO21848:STARtup:PROFile[:STATe] This command is used to analog ISO21848 startup wave of car. Command syntax CARWave:ISO21848:STARtup:PROFile[:STATe] 0|1 Arguments Reset Value Example CARWave:ISO21848:STARtup:PROFile 1 Copyright© Itech Electronics Co., Ltd.

  • Page 87: Carwave:iso16750:Load:dump[:State]

    Query syntax CARWave:ISO16750:LOAD:DUMP? Returns CARWave:ISO16750:LOAD:DUMP:TEST[:MODe] This command is used to select the test mode of load dump wave of car. Command syntax CARWave:ISO16750:LOAD:DUMP:TEST <AMODe|BMODe > Arguments AMODe|BMODe Reset Value AMODe Example CARW:ISO16750:LOAD:DUMP:TEST AMOD Query syntax CARWave:ISO16750:LOAD:DUMP:TEST? Copyright© Itech Electronics Co., Ltd.

  • Page 88: Carwave:iso16750:Load:dump[:Voltage]:Un[:Level]

    CARW:ISO16750:LOAD:DUMP:UN? [MINimum|MAXimum] Returns CARWave:ISO16750:LOAD:DUMP[:VOLTage]:US[:LEV This command is used to set the clamp voltage of load dump wave of car. Command syntax CARWave:ISO16750:LOAD:DUMP:US <value> Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARW:ISO16750:LOAD:DUMP:US 40 Query syntax CARW:ISO16750:LOAD:DUMP:US? [MINimum|MAXimum] Copyright© Itech Electronics Co., Ltd.

  • Page 89: Carwave:iso16750:Load:dump[:Time]:Td[:Level]

    CARW:ISO16750:LOAD:DUMP:TD 40 Query syntax CARW:ISO16750:LOAD:DUMP:TD? [MINimum|MAXimum] Returns CARWave:ISO16750:LOAD:DUMP:VOLTage[:LEVel] This command is used to set the voltage system of load dump. Command syntax CARWave:ISO16750:LOAD:DUMP:VOLT <12V|24V> Arguments 12V|24V Reset Value Example CARW:ISO16750:LOAD:DUMP:VOLT 12V Query syntax CARW:ISO16750:LOAD:DUMP:VOLT? Returns <CRD> Copyright© Itech Electronics Co., Ltd.

  • Page 90: Carwave:sae[:Test]:2B[:State]

    This command is used to select voltage system of SAEJ1113-11 TEST 2B. Command syntax CARWave:SAE:2B:VOLT <12V|24V> Arguments 12V|24V Reset Value Example CARWave:SAE:2B:VOLT 12V Query syntax CARWave:SAE:2B:VOLT? Returns <CRD> CARWave:SAE[:TEST]:2B[:TIMe]:TD[:LEVel] This command is used to set pulse width of SAEJ1113-11 TEST 2B Copyright© Itech Electronics Co., Ltd.

  • Page 91: Carwave:sae[:Test]:4[:State]

    This command is used to simulate SAEJ1113-11 TEST 4. Command syntax CARWave:SAE:4 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:SAE:4 1 Query syntax CARWave:SAE:4? Returns CARWave:SAE[:TEST]:4:VOLTage[:LEVel] This command is used to select voltage system of SAEJ1113-11 TEST 4 Command syntax CARWave:SAE:4:VOLT <12V|24V> Copyright© Itech Electronics Co., Ltd.

  • Page 92: Carwave:sae[:Test]:4[:Voltage]:Vs[:Level]

    CARWave:SAE:4:VS < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARWave:SAE:4:VS 10 Query syntax CARWave:SAE:4:VS? Returns CARWave:SAE[:TEST]:4[:VOLTage]:VA[:LEVel] This command is used to set Va of SAEJ1113-11 TEST 4. Command syntax CARWave:SAE:4:VA < value > Arguments MINimum|MAXimum|NR3 Copyright© Itech Electronics Co., Ltd.

  • Page 93: Carwave:sae[:Test]:4[:Time]:T7[:Level]

    CARWave:SAE:4:T7 < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARWave:SAE:4:T7 0.1 Query syntax CARWave:SAE:4:T7? Returns CARWave:SAE[:TEST]:4[:TIMe]:T9[:LEVel] This command is used to set T9 SAEJ1113-11 TEST 4. Command syntax CARWave:SAE:4:T9 < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Copyright© Itech Electronics Co., Ltd.

  • Page 94: Carwave:sae[:Test]:4[:Time]:T11[:Level]

    CARWave:SAE:4:T11 < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARWave:SAE:4:T11 0.1 Query syntax CARWave:SAE:4:T11? Returns CARWave:SAE[:TEST]:5[:STATe] This command is used to simulate SAEJ1113-11 TEST 5. Command syntax CARWave:SAE:5 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:SAE:5 1 Copyright© Itech Electronics Co., Ltd.

  • Page 95: Carwave:sae[:Test]:5:Test[:Mode]

    CARWave:SAE:5:TEST AMODe Query syntax CARWave:SAE:5:TEST? Returns <CRD> CARWave:SAE[:TEST]:5[:VOLTage]:UN[:LEVel] This command is used to set Un of SAEJ1113-11 TEST 5. Command syntax CARWave:SAE:5:UN < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARWave:SAE:5:UN 70 Query syntax CARWave:SAE:5:UN? Copyright© Itech Electronics Co., Ltd.

  • Page 96: Carwave:sae[:Test]:5[:Voltage]:Us[:Level]

    CARWave:SAE:5:US 50 Query syntax CARWave:SAE:5:US? Returns CARWave:SAE[:TEST]:5[:TIMe]:TD[:LEVel] This command is used to set Td of SAEJ1113-11 TEST 5 Command syntax CARWave:SAE:5:TD < value > Arguments MINimum|MAXimum|NR3 Reset Value MINimum Example CARWave:SAE:5:TD 0.2 Query syntax CARWave:SAE:5:TD? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 97: Carwave:sae[:Test]:5:Voltage[:Level]

    <CRD> CARWave:LV124:E02[:STATe] This command is used to simulate LV124 E02 wave. Command syntax CARWave:LV124:E02 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:LV124:E02 1 Query syntax CARWave:LV124:E02? Returns CARWave:LV124:E04[:STATe] This command is used to simulate LV124 E04. Copyright© Itech Electronics Co., Ltd.

  • Page 98: Carwave:lv124:E05[:State]

    This command is used to simulate LV124 E05. Command syntax CARWave:LV124:E05 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:LV124:E05 1 Query syntax CARWave:LV124:E05? Returns CARWave:LV124:E07[:STATe] This command is used to simulate LV124 E07. Command syntax CARWave:LV124:E07 <bool> Copyright© Itech Electronics Co., Ltd.

  • Page 99: Carwave:lv124:E07:Ubmax[:Level]

    CARWave:LV124:E07:UBMAX < value > Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E07:UBMAX 50 Query syntax CARWave:LV124:E07:UBMAX? Returns CARWave:LV124:E07:UBMIN[:LEVel] This command is used to set keeping voltage Ubmin of LV124 E07. Command syntax CARWave:LV124:E07:UBMIN < value > Arguments MINimum|MAXimum|NR3 Copyright© Itech Electronics Co., Ltd.

  • Page 100: Carwave:lv124:E07[:Ubmin]:Time

    This command is used to set keeping voltage duration of LV124 E07 Command syntax CARWave:LV124:E07:TIM < value > Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E07:TIM 1 Query syntax CARWave:LV124:E07:TIM? Returns CARWave:LV124:E08[:STATe] This command is used to simulate LV124 E08. Command syntax CARWave:LV124:E08 <bool> Arguments ON|OFF|1|0 Reset Value Copyright© Itech Electronics Co., Ltd.

  • Page 101: Carwave:lv124:E08:Ubmax[:Level]

    Reset Value Example CARWave:LV124:E08:UBMAX 50 Query syntax CARWave:LV124:E08:UBMAX? Returns CARWave:LV124:E08:UBMIN[:LEVel] This command is used to set keeping voltage Ubmin of LV124 E08. Command syntax CARWave:LV124:E08:UBMIN < value > Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E08:UBMIN 20 Copyright© Itech Electronics Co., Ltd.

  • Page 102: Carwave:lv124:E08[:Ubmin]:Time

    CARWave:LV124:E08:TIM < value > Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E08:TIM 1 Query syntax CARWave:LV124:E08:TIM? Returns CARWave:LV124:E09[:STATe] This command is used to simulation LV124 E09. Command syntax CARWave:LV124:E09 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:LV124:E09 1 Query syntax CARWave:LV124:E09? Copyright© Itech Electronics Co., Ltd.

  • Page 103: Carwave:lv124:E09:Ubmin[:Level]

    Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E09:UBMIN 20 Query syntax CARWave:LV124:E09:UBMIN? Returns CARWave:LV124:E11[:STATe] This command is used to simulate LV124 E11. Command syntax CARWave:LV124:E11 <bool> Arguments ON|OFF|1|0 Reset Value Example CARWave:LV124:E11 1 Query syntax CARWave:LV124:E11? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 104: Carwave:lv124:E11:Test:mode

    This command is used to select pulse mode of LV124 E11. Command syntax CARWave:LV124:E11:PULS:MODE <NORMal|SEVEre > Arguments NORMal | SEVEre Reset Value NORMal Example CARWave:LV124:E1:PULS:MODE NORMal Query syntax CARWave:LV124:E1:PULS:MODE? Returns <CRD> CARWave:LV124:E12[:STATe] This command is simulate LV124 E12. Copyright© Itech Electronics Co., Ltd.

  • Page 105: Carwave:lv124:E12:Deltau[:Level]

    Query syntax CARWave:LV124:E12? Returns CARWave:LV124:E12:DELTAU[:LEVel] This command is used to set voltage drop ΔU value of LV124 E12. Command syntax CARWave:LV124:E12:DELTAU < value > Arguments MINimum|MAXimum|NR3 Reset Value Example CARWave:LV124:E12:DELTAU 2 Query syntax CARWave:LV124:E12:DELTAU? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 106: Chapter13 Battery Charge And Discharge Statistic Command

    Example BATT:CAP:CLE FETCh:BATTery:CAPacity[:CHARge]? This command is used to obtain battery charge capacity. Command syntax FETCh:BATTery:CAPacity[:CHARge]? ReturnsUnit Returns: Example FETC:BATT:CAP? ->3.00 FETCh:BATTery:CAPacity:DISCharge? This command is used to obtain battery discharge capacity. Command syntax FETCh:BATTery:CAPacity:DISCharge? ReturnsArguments Returns Copyright© Itech Electronics Co., Ltd.
  • Page 107 Battery Charge and Discharge Statistic Command Example FETC:BATT:CAP:DISC? ->4.0 Copyright© Itech Electronics Co., Ltd.

  • Page 108: Chapter14 Calibration Command

    This command is used to Command syntax CALibrate:VOLTage:LEVel <P0|P1> Arguments P0|P1 Example CAL:VOLT:LEV P0 CALibrate:VOLTage[:DATA] This command is used to read the actual voltage of the present calibration point. Command syntax CALibrate:VOLTage[:DATA] <NRf> Arguments Unit Copyright© Itech Electronics Co., Ltd.

  • Page 109: Calibrate:current:level

    CALibrate:MONitor:VOLTage:LEVel This command is used to set monitoring the voltage calibration point. Command syntax CALibrate:MONitor:VOLTage:LEVel <P0|P1> Arguments P0|P1 Example CAL:MON:VOLT:LEV P0 CALibrate:MONitor:VOLTage[:DATA] This command is used to set the voltage calibration point data for monitoring. Copyright© Itech Electronics Co., Ltd.

  • Page 110: Calibrate:monitor:current:level

    This command is used to current calibration point data for monitoring. Command syntax CALibrate:MONitor:CURRent[:DATA] <NRf> Arguments Unit Example CAL:MON:CURR 15.0 CALibrate:PROGram:VOLTage:LEVel This command is used to set voltage calibration point for programming. Command syntax CALibrate:PROGram:VOLTage:LEVel <P0|P1> Copyright© Itech Electronics Co., Ltd.

  • Page 111: Calibrate:program:voltage[:Data]

    This command is used to set calibration point of program current. Command syntax CALibrate:PROGram:CURRent:LEVel <P0|P1> Arguments P0|P1 Example CAL:PROG:CURR:LEV P0 CALibrate:PROGram:CURRent[:DATA] This command is used to set calibration data of program current. Command syntax CALibrate:PROGram:CURRent[:DATA] <NRf> Arguments Unit Copyright© Itech Electronics Co., Ltd.

  • Page 112: Calibrate:equal:input:current:level

    This command is used to set calibration point of current sharing output current. Command syntax CALibrate:EQUal:OUTPut:CURRent:LEVel <P0|P1> Arguments P0|P1 Example CAL:EQU:OUTP:CURR:LEV P0 CALibrate:EQUal:OUTPut:CURRent[:DATA] This command is used to set calibration data of current sharing output current. Copyright© Itech Electronics Co., Ltd.

  • Page 113: Calibrate:summary:output:current:level

    CALibrate:SUMMary:OUTPut:CURRent[:DATA] This command is used to set calibration data of summary current. Command syntax CALibrate:SUMMary:OUTPut:CURRent[:DATA] <NRf> Arguments Unit Example CAL:SUMM:OUTP:CURR 20.0 CALibrate:SAVe This command is used to save the calibration parameters in a nonvolatile memory. Copyright© Itech Electronics Co., Ltd.

  • Page 114: Calibrate:initialize

    Calibration Command Command syntax CALibrate:SAVe Example CAL:SAV CALibrate:INITialize This command is used to initialize the calibration parameters. Command syntax CALibrate:INITialize Example CAL:INIT Copyright© Itech Electronics Co., Ltd.

  • Page 115: Chapter15 Parallel Related Command

    This command is used to set link role. Command syntax LINK:ROLE <SLAVe|MASTer> Arguments SLAVe|MASTer Example LINK:ROLE slav Query syntax LINK:ROLE？ Returns <CRD> LINK:NUMBer This command is used to set link number. Command syntax LINK:NUMBer <MINimum|MAXimum|NR1 > Copyright© Itech Electronics Co., Ltd.
  • Page 116 Parallel Related Command Arguments MINimum|MAXimum|<2-32> Example LINK:NUMB 1 Query syntax LINK:NUMBer? Returns Copyright© Itech Electronics Co., Ltd.

  • Page 117: Chapter16 Tracerelated Command(It6500C)

    This command is used to select cache control. Select NEVer, Save to Cache is disabled; select NEXT, save process starts and will stop when the cache is filled in. Select ALWays. After cache is filled in, circulate the cache. Copyright© Itech Electronics Co., Ltd.

  • Page 118: Trace:feed:selected

    Command syntax TRACe:FEED:SELected <CRD> Command Arguments VOLTage|CURRent|BOTH Example TRAC:FEED:SEL VOLT Query syntax TRACe:FEED:SELected? Returns <CRD> TRACe:DELay This command is used to select cache delay time. Command syntax TRACe:DELay<NRf> Command Arguments 0 to3600s|MINimum|MAXimum|Default Unit Copyright© Itech Electronics Co., Ltd.

  • Page 119: Trace:timer

    When Auto Clear is enabled, when saving starts, buffer will be automatically cleared; when it is disabled, the new reading will be saved to the buffer area following the previous data till the buffer is full or when saving stops. Command syntax TRACe:CLEar:AUTO[:STATe] <bool> Copyright© Itech Electronics Co., Ltd.

  • Page 120: Trace:data

    TraceRelated Command(IT6500C) Arguments 0|1|OFF|ON Query syntax TRACe:CLEar:AUTO[:STATe]? Returns TRACe:DATA? This command is used to read all values saved in the cache. Command syntax TRACe:DATA? Returns { <NR3>,<NR3>,<NR3>…} Copyright© Itech Electronics Co., Ltd.

  • Page 121: Chapter17 Ieee-488 Commands

    ESB of status byte register is 1. Command syntax *ESE <NR1> Arguments 0～255 Default set Refer to *PSC command Example *ESE 128 Query syntax *ESE? Returns <NR1> Related Command *ESR? *PSC *STB? Copyright© Itech Electronics Co., Ltd.

  • Page 122: Esr

    None Returns segment description <AARD> Example ITECH,IT6522C,601234567890123456,1.03-1.02 *OPC When all commands before this command are executed, bit OPC in standard event register will be set to 1. Command syntax *OPC Arguments None Query syntax *OPC? Copyright© Itech Electronics Co., Ltd.

  • Page 123: Psc

    1 and the byte will set RQS of state byte register to 1. Bit definition of state byte enable register is as the same as the state byte register. Command syntax *SRE <NRf> Arguments 0～255 Copyright© Itech Electronics Co., Ltd.

  • Page 124: Stb

    Query syntax *STB? Arguments None Returns <NR1> Related Command *CLS *ESE *ESR *SAV This command can save the current setups of power supply to specified memory. These setups contains current setups, voltage setups, max voltage Copyright© Itech Electronics Co., Ltd.

  • Page 125: Rcl

    This command is used to query the self-test by the instrument. 0 indicates that self-test succeeds; other Arguments indicate self-test fails. In addition, in case of failure, an error information will be generated to describe failure reason. Command syntax *TST? Arguments None Returns <NR1> Copyright© Itech Electronics Co., Ltd.
  • Page 126 Contact US Thank you for purchasing ITECH products.If you have any doubt about this product,please contact us as follow. 1. Please refer to the CD-ROM of related user’s manual in package. 2. Visit ITECH website www.itechate.com 3. Select the most convenient contact for further consultation.
