5.2 LAN Interface

Connect Interface
The operation steps to change the USB interface type in System Menu are as
follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Rotate the knob or press the Up/Down key to select 6. I/O Con and press
[Enter].
3. Rotate the knob or press the Left/Right key to select the communication
method, and press [Enter].
If you select VCP, you also need to set the baud rate and other parameters
of the virtual serial port, and the baud rate must be the same as the configu-
ration on the computer side.
Use the following steps to quickly connect your instrument to your LAN and con-
figure it. Two typical LAN interface systems are described below: private LAN
and site LAN.
•
Connect to the private LAN
A private LAN is a network in which LAN-enabled instruments and com-
puters are directly connected. They are typically small, with no centrally-
managed resources. When connected to a computer, a crossover cable can
be used to connect directly to the computer via the LAN interface.
•
Connect to the site LAN
A site LAN is a local area network in which LAN-enabled instruments and
computers are connected to the network through routers, hubs, and/or
switches. They are typically large, centrally-managed networks with services
such as DHCP and DNS servers. When connected to a computer, a direct-
attached network cable can be used to connect to the router, and the com-
puter is also connected to the router.
•
When using one crossover cable to connect PC directly, the gateway address of
the instrument should be consistent with that of the PC, and the IP address
should be at the same network segment with the PC's IP address.
•
When the instrument and computer are connected to the router, an independent
IP address must be assigned for the instrument.
