5.3 CAN Interface

Definition of CAN Pins
CAN Configuration
6. Rotate the knob to select whether to enable the service and press
[Enter].
– On: Indicates that the service is enabled.
– Off: Indicates that the service is disabled.
The CAN interface is located on the rear panel of the instrument and is con-
nected to the computer using a CAN communication cable.
The definition of CAN pins are as follows.
Pins
H
L
The user needs to configure the CAN interface parameters in the system menu
before using the remote control. The CAN interface parameters are as follows.
Name Description
Baud rate Select the baud rate from the following options: 20k/40k/50k/
80k/100k/125k/150k/200k/250k/400k/500k/1000k
Instrument Range: 1 – 65535
Address
The operation steps are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Rotate the knob or press the Up/Down key to select 6. I/O Con and press
[Enter].
3. Press the Left/Right key to select CAN and press [Enter].
4. Set the baud rate, address and other parameters, press [Enter].
