The type of the fuse The way to replace
1. Use a screwdriver to push and turn the
2. The fuse box will bounce up, then you can
3. Please replace with a fuse of the same
4. When install, put into the fuse box as the
The power cord jack of the instrument includes
the fuse. Please refer to the rear panel intro-
duction of the corresponding instrument for
the detailed position. The replacement steps
for this type of the fuse are as follows.
1. First pull out the power cord, and then take
2. Have a visual inspection of the fuse to see
Copyright © Itech Electronic Co., Ltd.
fuse box anti-clockwise. When turned to 90
degrees, release the screwdriver. Refer to
the picture below.
see the fuse in it. Take out the blown fuse.
specification. Refer to the technical specifi-
cation of the corresponding instrument.
picture below. Then use a screwdriver to
push and turn the fuse box to 90 degrees
clockwise. Refer to the picture below.
out the fuse block from the power cord jack
with a small screwdriver, as shown below.
whether it is burnt out; if yes, replace it with
another fuse of the same specification. Re-
fer to the corresponding technical specifi-
cations for fuse rating.
