2.2.2 Push-on Knob

Adjust the Value Setting
Select Menu Item
Keys Description
[Shift]+[+/–] Save the common parameter settings.
(Save)
+/– Positive and negative signs
. Decimal point
Left / Right navi- The left and right navigation keys are used to adjust the
gation keys cursor to the specified position or scrolls pages to view
menu items.
Up / Down navi- The up and down navigation keys are used to scroll page
gation keys up and down to view menu items.
[Enter] Operation confirmation key
The IT6000C series Bi-directional Programmable DC Power Supply provides a
knob on the front panel as shown in the next figure.
The functions of the posh-on knob is described as follows.
•
Adjust the value setting
•
Select menu item
•
Confirm the set value or the selected menu item
In the value setting interface, rotate the knob clockwise to increase the set value
and anticlockwise to decrease the set value.
The knob can also be used to view menu items. In the menu item display inter-
face, turning the knob clockwise indicates that the next menu item is selected,
and turning the knob anticlockwise indicates that the previous menu item is
selected.
