4.6.2 Battery Charging/Discharging Test Function

The IT6000C series power supply provides the battery charging/discharging test
function based on its unique bipolar power supply properties. Suitable for charg-
ing/discharging tests on all types of portable batteries.
Battery charging/discharging test function
BATTERY
Run
Edit
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
Copyright © Itech Electronic Co., Ltd.
Indicates that the battery test mode is entered and
waits to trigger the running of the currently edited bat-
tery test file.
Edit the battery charging/discharging test file.
Set the test mode:
•
•
Charge /
Discharge
According to the test require-
ments, choose one to set.
Charge /
Discharge
V
Charge /
Discharg I
Charge /
Discharg
Time
Cut Off Voltage Battery test cut-off voltage
Battery test cut-off current
Cut Off Current
Cut Off Capacity Battery test cut-off capacity
www.tehencom.com
Power Supply Function
Charge: Battery charging
Discharge: Battery
discharging
Set the voltage
value for charging
or discharging ac-
cording to the se-
lected test mode.
Set the current val-
ue for charging or
discharging ac-
cording to the se-
lected test mode.
Set the charging
or discharging
time according to
the selected test
mode.
