3.6.4 Select Trigger Source (Trig Source)

1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Press the Up/Down key or turn the knob to select the Sense and press
[Enter].
3. Press the Left / Right key or turn the knob to adjust the value of this
parameter.
•
Off: Default value, indicates turn the sense function off.
•
On: Indicates turn the sense function on.
4. After the parameter settings are complete, press [Enter].
For the IT6000C series power supply, the List and data logging functions can be
triggered for running by the following methods:
•
Manual: Default value, indicates the trigger occurs when the
[Shift]+[On/Off] (Trigger) keys are pressed from the front panel.
•
Bus: Indicates the trigger occurs via the communication cables. When the
trigger command *TRG is received, the IT6000C instrument generates a
trigger.
•
External: Indicates the trigger occurs via the pin 4 of the digital I/O interface
(P-IO).
For details, see 3.6.7.4 IO–4. Ext-Trig,
The List function and the data logging function have the same steps for select-
ing the trigger source. They need to be set separately in different menu items
(ListTrig Source and DataLogger Trig Source). Therefore, this section takes
the List trigger source setting as an example to introduce the operation steps.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Press the Up/Down key or turn the knob to select the ListTrig Source and
press [Enter].
•
When setting the trigger source for data logging, select the
DataLogger Trig Source menu item.
•
The List trigger source set here is also valid for triggering other functions in
the Function menu.
