Configure the Function Menu
The user can select the following data sources for recording:
•
Voltage
Only records voltage data during the data acquisition period.
•
Current
Only records current data during the data acquisition period.
•
Voltage and current
Records current and voltage data during the data acquisition period.
1. Press the composite button [Shift]+[1] (Log) on the front panel to enter the
configuration menu of the data logging function.
The parameters are described as follows:
Menu Item Description
Sample This parameter indicates the data
Period sampling interval (unit: s), that is, the
test data is recorded once every X
seconds.
The input range supported by the in-
strument is: 0 - 9
Duration This parameter indicates the time for
data recording (unit: s), namely, the
data recording will be completed in Y
seconds and be ready for the next
data record.
The input range supported by the in-
strument is: 0 - 3600
Source This parameter indicates the source
of recorded data, including voltage
(V), current (I), voltage and current
(V/I).
Copyright © Itech Electronic Co., Ltd.
www.tehencom.com
Basic Operation
Setting
Set the value by in-
putting the value
through the number
key or rotating the
knob.
Use the Left and
Right arrow key or
the rotation knob to
select.
