Recall the Vehicle Waveform
Run the Vehicle Waveform
•
DIN40839
•
ISO16750-2
•
ISO21848
•
SAEJ1113–11
•
LV124
The following is a general overview of this function menu, and the detailed pa-
rameters of the waveform corresponding to each protocol/standard can be
found in the corresponding chapter.
Road- Vehicle waveform function menu
Vehicles
DIN40839
ISO16750-2
ISO21848
SAEJ1113-11
LV124
Select any of the above five kinds of vehicle waveforms, after completing the
waveform parameter setting (see the subsequent introduction for each parame-
ter), the system will automatically enter the waveform recalling mode and wait
for the triggering operation. At this time, the VFD screen is displayed as the
main interface of the system, and the corresponding waveform name is dis-
played in the lower right corner.
After turning on [On/Off], the output of the vehicle waveform is triggered accord-
ing to the selected trigger method.
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Evaluation of automotive starting
waveform
Simulate the waveform to verify the
anti-interference performance of the au-
tomotive electronics' products.
42V Road vehicles — Electrical and
electronic equipment for a supply volt-
age of 42 V — Electrical loads
SAEJ1113-11 Waveform protocol
LV124 Waveform protocol
