2564 Barcode Scanner
Setup barcodes included.
Version 1.00

Advertisement

Table of Contents
loading

Related Manuals for CipherLab 2564

Summary of Contents for CipherLab 2564

  • Page 1 2564 Barcode Scanner Setup barcodes included. Version 1.00...
  • Page 2 Due to continued product development this information may change without notice. The information and intellectual property contained herein is confidential between CIPHERLAB and the client and remains the exclusive property of CIPHERLAB CO., LTD. If finding any problems in the documentation, please report them to us in writing. CIPHERLAB does not warrant that this document is error-free.

  • Page 3: For Canada

    IMPORTANT NOTICES FOR USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 4: For Product With Laser

    FOR PRODUCT WITH LASER CAUTION This laser component emits FDA / IEC Class 2 laser light at the exit port. Do not stare into beam. SAFETY PRECAUTIONS DO NOT expose the scanner to any flammable sources.  Under no circumstances, internal components are self-serviceable. ...

  • Page 5: Release Notes

    RELEASE NOTES Version Date Notes  Initial Release 1.00 Sep. 27, 2017...

  • Page 7: Table Of Contents

    CONTENTS IMPORTANT NOTICES ......................- 3 - For USA............................- 3 - For Canada ..........................- 3 - For Product with Laser ......................- 4 - Safety Precautions ........................- 4 - Care & Maintenance........................ - 4 - RELEASE NOTES ........................- 5 - INTRODUCTION........................
  • Page 8 2564 Barcode Scanner User Guide 1.2.3 Free Memory ......................28 1.3 LED Indicator ........................29 1.3.1 Good Read LED ......................30 1.3.2 Good Read LED Duration ..................30 1.4 Beeper ............................ 31 1.4.1 Beeper Volume ......................32 1.4.2 Good Read Beep ....................... 33 1.4.3 Low Battery Alarm ....................
  • Page 9 2564 Barcode Scanner User Guide 2.2 BT SPP Slave ........................61 2.2.1 Activate BT SPP Slave Mode ................. 61 2.2.2 Inter-Function Delay ....................61 2.2.3 ACK/NAK Timeout ....................61 2.2.4 BT SPP Slave Hardware Flow Control ............... 62 2.3 BT SPP Master ........................63 2.3.1 Activate BT SPP Master Mode ................
  • Page 10 2564 Barcode Scanner User Guide 3.1.1 Connect to Cradle ..................... 98 3.1.2 Change Interface ...................... 99 3.1.3 Configure Related Settings ................. 100 ® 3.2 Connecting via Bluetooth Dongle ................100 3.2.1 Change Interface ....................100 3.2.2 Configure Related Settings ................. 101 3.2.3 Connect to Dongle ....................
  • Page 11 2564 Barcode Scanner User Guide 4.9.1 EAN-13 Addon Modes ................... 135 4.9.2 Convert to ISBN ...................... 137 4.9.3 Convert to ISSN ...................... 137 4.9.4 Transmit Check Digit ..................... 138 4.9.5 Security Level ......................138 4.10 GS1-128 (EAN-128) ..................... 139 4.10.1 Transmit Code ID ....................139 4.10.2 Field Separator (GS Character) ..............
  • Page 12 2564 Barcode Scanner User Guide 4.20.3 Security Level ......................159 4.20.4 Code Length Qualification ................. 159 4.21 Composite Code ......................161 4.21.1 Composite CC-A/B ....................161 4.21.2 Composite CC-C ....................161 4.21.3 UPC Composite Mode ..................162 4.22 2D Symbologies ......................163 4.22.1 PDF417 ........................
  • Page 13 2564 Barcode Scanner User Guide 6.4.3 Total Number of Fields ..................219 6.4.4 Field Settings......................220 6.4.5 Pause Field Setting ....................226 6.5 Configuring Format — Define Transmission Sequence ........227 6.6 Programming Examples ....................229 6.6.1 Example I ........................229 6.6.2 Example II .........................
  • Page 14 2564 Barcode Scanner User Guide Keyboard Wedge (Cradle) ....................270 Remote USB HID (Cradle) ....................275...

  • Page 15: Introduction

    Owing to the slim, ergonomic design, extremely low power consumption, and powerful decoding capability, CipherLab Barcode Scanners are the best choice for the following applications – Receiving in Retail ...

  • Page 16: Getting Familiarized With The Scanner And The Cradle

    2564 Barcode Scanner User Guide GETTING FAMILIARIZED WITH THE SCANNER AND THE CRADLE INSTALLING THE BATTERY TO THE SCANNER When you first receive the package, the rechargeable battery is stored separately from the scanner. Insert the battery into the scanner first so that it can be charged when sitting in the cradle.

  • Page 17: Setting Up The Cradle

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат SETTING UP THE CRADLE Capable of charging the scanner, the cradle is specifically designed for the scanner to communicate with a host computer wirelessly. Refer to 3.1.1 Connect to Cradle.

  • Page 18: Charging The Battery Via Cradle

    2564 Barcode Scanner User Guide CHARGING THE BATTERY VIA CRADLE The battery may not be charged to full for shipment. When you first receive the package, you will need to charge the battery to full before using the scanner. When using the RS-232 cable, it takes approximately 5 hours to charge the battery to full (from the power adaptor).

  • Page 19: Charging The Battery Via Charger

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат CHARGING THE BATTERY VIA CHARGER The battery charger is provided for charging the battery only. You may purchase the charger separately. It takes approximately 3 hours to charge the battery to full. Note: Battery charging stops when the temperature drops below 0°C or exceeds 40°C.

  • Page 20: Inside The Package

    2564 Barcode Scanner User Guide INSIDE THE PACKAGE The items included in the package may be different depending on your order. Rich choices of output interfaces are available to enhance the total performance of the scanner. Please refer to product specifications.

  • Page 21: Symbologies Supported

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат SYMBOLOGIES SUPPORTED Most of the popular barcode symbologies are supported, as listed below. Each can be individually enabled or disabled. The scanner will automatically discriminate and recognize all the symbologies that are enabled.
  • Page 22 2564 Barcode Scanner User Guide GS1 DataBar Limited (RSS Limited) Disabled GS1 DataBar Expanded (RSS Expanded) Disabled Composite Composite CC-A/B Disabled Code Composite CC-C Disabled PDF417 Enabled Symbologies MicroPDF417 Disabled Data Matrix Enabled Maxicode Enabled QR Code Enabled MicroQR Disabled...

  • Page 23: Quick Start

    QUICK START The configuration of the scanner can be done by reading the setup barcodes contained in this manual or via the ScanMaster software. This section describes the procedure of configuring the scanner by reading the setup barcodes and provides some examples for demonstration. Configuration Mode Hold down the trigger about 2 seconds to turn on the scanner.
  • Page 24 2564 Barcode Scanner User Guide Working Mode Upon powering up, the scanner will try to establish a connection with the BT cradle or a computer ® with Bluetooth wireless technology. Refer to Chapter 3 Setting up a WPAN Connection for details.

  • Page 25: Enter Configuration Mode

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат ENTER CONFIGURATION MODE For the scanner to enter the configuration mode, have it read the "Enter Setup" barcode located at the bottom of almost every even page of this manual. The scanner will respond with six beeps and its LED indicator will become flashing red ...

  • Page 26: Default Settings

    2564 Barcode Scanner User Guide DEFAULT SETTINGS SAVE USER SETTINGS AS DEFAULTS For the scanner to keep the customized settings as user defaults, have it read the “Save as User Defaults” barcode. This is a normal setup barcode, and the scanner will respond with two beeps (low-high tone).

  • Page 27: Read A Setup Barcode

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат READ A SETUP BARCODE CONFIGURE PARAMETERS For most of the scanner parameters, only one read is required to set them to new values. The scanner will respond with two beeps (low-high tone) when each parameter is set successfully.
  • Page 28 2564 Barcode Scanner User Guide The example below shows how to save settings as “User Default” to restore user defaults later: Steps Action Scanner Feedback if Successful Power on the scanner… The scanner will respond with a long beep (high tone) and its LED indicator will become solid red and go off quickly.
  • Page 29 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат The example below shows how to set numeric parameters: Steps Action Scanner Feedback if Successful Power on the scanner... The scanner will respond with a long beep (high tone) and its LED indicator will become solid red and go off quickly.
  • Page 30 2564 Barcode Scanner User Guide The example below shows how to set string parameters: Steps Action Scanner Feedback if Successful Power on the scanner... The scanner will respond with a long beep (high tone) and its LED indicator will become solid red and go off quickly.

  • Page 31: List The Current Settings

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат LIST THE CURRENT SETTINGS The current settings of all scanner parameters can be sent to the host computer for user inspection. The listing includes pages as shown below. Select the page of interest by having the scanner read the “List Page x”...
  • Page 32 2564 Barcode Scanner User Guide Lists settings regarding Editing Format 1 List Page 11 (1/2) Lists settings regarding Editing Format 1 List Page 12 (2/2) Lists settings regarding Editing Format 2 List Page 13 (1/2) Lists settings regarding Editing Format 2...

  • Page 33: Create One-Scan Setup Barcodes

    Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображат CREATE ONE-SCAN SETUP BARCODES Most of the scanner parameters require only one read for setting new values. To facilitate configuring the scanner, create One-Scan setup barcodes for use. 1D ONE-SCAN BARCODE The requirements of a One-Scan setup barcode are: a prefix of the “#@”...

  • Page 34: One-Scan Barcode

    2564 Barcode Scanner User Guide 2D ONE-SCAN BARCODE Users can also scan a single 2D barcode combining with a series of serial commands to configure the scanner. For example, if you want to change the suffix character to ‘#’, you...

  • Page 35: Understanding The Barcode Scanner

    Chapter 1 UNDERSTANDING THE BARCODE SCANNER This chapter explains the features and usage of the barcode scanner. IN THIS CHAPTER 1.1 Battery ..............21 1.2 Memory ..............26 1.3 LED Indicator ............. 29 1.4 Beeper............... 31 1.5 Send “NR” to Host ............35 1.6 Scan Modes ..............

  • Page 36: Power Economy

    2564 Barcode Scanner User Guide 1.1.2 POWER ECONOMY The scanner features “Power-Saving” and “Auto Power Off” giving consideration to the power issue that is generally critical for Bluetooth-enabled devices. By the scanner’s support of power economy, its power consumption may progress by the following...
  • Page 37 Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Note: Power-Saving won’t take effect when one of the following conditions is met: (1) the scanner has already established a BT HID/SPP connection, (2) the scanner is in the configuration mode, (3) the setting value of Power-Saving is greater than that of Auto Power Off.

  • Page 38: Power Economy Vs. Wpan Connection

    2564 Barcode Scanner User Guide 1.1.3 POWER ECONOMY VS. WPAN CONNECTION Before the scanner can communicate with the host computer, Bluetooth connection (or WPAN connection) needs to be established. The scanner’s power economy always accommodates itself to the establishment of the WPAN connection.
  • Page 39 Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь from low to high upon the resumption. If the scanner fails to resume the connection, it will try every 5 seconds to re-connect to the host unless you have the scanner read the “Reset Connection”...

  • Page 40: Memory

    2564 Barcode Scanner User Guide 1.2 MEMORY The collected data can be sent back to a host computer one by one via the WPAN connection or stored in flash memory when the scanner is set to Memory mode. 1.2.1 TRANSMIT BUFFER By default, transmit buffer is enabled and for use when the scanner is out of range.

  • Page 41: Memory Mode

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.2.2 MEMORY MODE The scanner keeps 4 MB flash memory for memory mode operation. When the scanner is in memory mode, it means any real-time connection established with host is disabled. Enable *Disable Warning:...

  • Page 42: Free Memory

    2564 Barcode Scanner User Guide 8 sec Send Data The 4 MB flash memory on the scanner can store up to 246,723 scans based on EAN-13 barcodes. When it is used up, the scanner will respond with two short beeps (high-low tone) as a warning.

  • Page 43: Led Indicator

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.3 LED INDICATOR The triple-color LED on top of the scanner is used to provide user feedback. For example, the LED becomes solid red and goes off quickly upon powering on or running out of transmit buffer.

  • Page 44: Good Read Led

    2564 Barcode Scanner User Guide 1.3.1 GOOD READ LED *Enable Good Read LED Disable Good Read LED 1.3.2 GOOD READ LED DURATION By default, the Good Read LED stays on for 40 milliseconds. Specify a value, ranging from 1 to 254 in units of 10 milliseconds.

  • Page 45: Beeper

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.4 BEEPER The scanner has a buzzer to give feedback for various operating conditions. Beeping Meaning One long beep, high tone Power on, with red LED on (1 second) and off quickly One short beep, high tone Good Read, with green LED on-off quickly ...

  • Page 46: Beeper Volume

    2564 Barcode Scanner User Guide 1.4.1 BEEPER VOLUME Mute Minimum Volume Medium Volume *Maximum Volume Enter Setup...

  • Page 47: Good Read Beep

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.4.2 GOOD READ BEEP Frequency 8 kHz *4 kHz 2 kHz 1 kHz Duration *Shortest Shorter Longer Longest Update...

  • Page 48: Low Battery Alarm

    2564 Barcode Scanner User Guide 1.4.3 LOW BATTERY ALARM By default, it will activate the beeper to give a warning when the battery charge gets low. In order to prevent data loss, you are advised to replace the battery immediately when you hear two short beeps (high tone).

  • Page 49: Send "Nr" To Host

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.5 SEND “NR” TO HOST This feature only works when Keyboard Wedge or RS-232 is selected for output interface. Have the scanner send the “NR” string to the host to notify the No Read event. Enable *Disable Update...

  • Page 50: Scan Modes

    2564 Barcode Scanner User Guide 1.6 SCAN MODES Different scan modes are supported – select the scan mode that best suits the requirements of a specific application. Refer to the comparison table below. Scan Mode Start to Scan Stop Scanning...

  • Page 51: Laser Mode

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.6.1 LASER MODE The scanner will start scanning once the trigger is held down. The scanning won't stop until (1) a barcode is decoded, (2) the pre-set timeout ...

  • Page 52: Aiming Mode

    2564 Barcode Scanner User Guide 1.6.4 AIMING MODE The scanner will aim at a barcode once the trigger is pressed, and start scanning when the trigger is pressed again within one second. The scanning won't stop until (1) a barcode is decoded, and (2) the pre-set timeout ...

  • Page 53: Presentation Mode

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.6.6 PRESENTATION MODE The scanner will be expecting barcodes. Whenever a barcode is brought within range, the scanner will be able to decode it. It is suggested to seat the scanner in the Auto-Sense Stand for hands-free operation.

  • Page 54: Scanning Timeout

    2564 Barcode Scanner User Guide 1.7 SCANNING TIMEOUT Specify the scanning time interval (1~254 sec.; 0= Disable) when the scan mode is set to any of the following – Laser mode  Auto Off mode  Auto Power Off mode ...

  • Page 55: Delay Between Re-Read

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.8 DELAY BETWEEN RE-READ This is also referred to as the “Blocking Time”, which is used to prevent the scanner from accidentally reading the same barcode twice when the scan mode is set to any of the following –...

  • Page 56: Read Redundancy (1D)

    2564 Barcode Scanner User Guide 1.9 READ REDUNDANCY (1D) Select the level of reading redundancy. For example, If "No Redundancy" is selected, one successful decoding will make the reading valid  and induce the "READER Event". If "Two Times" is selected, it will take a total of three consecutive successful decoding ...

  • Page 57: Addon Security For Upc/Ean Barcodes

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.10 ADDON SECURITY FOR UPC/EAN BARCODES The scanner is capable of decoding a mix of UPC/EAN barcodes with or without addons. The read redundancy (2~30 times; default is set to 2) allows changing the number of times to decode a UPC/EAN barcode before transmission.

  • Page 58: Cable Auto-Detection Via Bt Cradle

    2564 Barcode Scanner User Guide 1.12 CABLE AUTO-DETECTION VIA BT CRADLE By default, this function is enabled that the cradle will detect the interface automatically. Connect the BT cradle to a host computer using the provided interface cable. After the BT...

  • Page 59: Mobile Phone/Display Mode

    Chapter 1 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 1.14 MOBILE PHONE/DISPLAY MODE By default this mode is disabled. There is a big improvement in reading barcodes displayed on mobile phones and electronic displays when this mode is enabled. *Disable Enable 1.15 SERIAL NUMBER STAMP...

  • Page 60: Decode Settings

    2564 Barcode Scanner User Guide 1.16 2D DECODE SETTINGS 1.16.1 AIMING PATTERN Enable/Disable the aiming pattern during scanning. *Enable Disable 1.16.2 DECODING ILLUMINATION Enable/Disable illumination during scanning. Enabling illumination usually results in superior images. The effectiveness of the  illumination decreases as the distance to the target increases.

  • Page 61: Selecting Output Interface

    Chapter 2 SELECTING OUTPUT INTERFACE In order to establish a proper WPAN connection between your computer and the scanner, we suggest that you follow these instructions – 1) Install the battery and hold down the trigger for about 2 seconds to turn on the scanner.

  • Page 62: Bt Hid

    2564 Barcode Scanner User Guide 2.1 BT HID For BT HID, refer to Chapter 3 Setting up a WPAN Connection for related connection settings. Run any text editor on your computer, and the scanned data will be transmitted to the computer.

  • Page 63: Activate Bt Hid & Select Keyboard Type

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.1.1 ACTIVATE BT HID & SELECT KEYBOARD TYPE When BT HID interface is activated, you will have to select a keyboard type to complete this setting. By default, BT HID is activated on the scanner, and the keyboard type is set to PCAT (US).

  • Page 64: Reset Connection

    2564 Barcode Scanner User Guide 2.1.2 RESET CONNECTION For BT HID, you can only have the scanner connected to one computer at a time. If you want to connect the scanner to another host, you must have it read the “Reset Connection”...

  • Page 65: Keyboard Settings

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.1.3 KEYBOARD SETTINGS Alphabets Layout  Digits Layout  Capital Lock Type  Capital Lock Setting  Alphabets Transmission   Digits Transmission Kanji Transmission ...
  • Page 66 2564 Barcode Scanner User Guide US Keyboard Style – Normal QWERTY layout, which is normally used in western countries.  Select “Lower Row” for the “Digits Layout” setting because the upper row is for special characters. French Keyboard Style – AZERTY French layout;...
  • Page 67 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Digits Layout Select a proper layout that matches the alphabets layout. The scanner will make adjustments according to this setting. Options Description Normal Depends on the [Shift] key or [Shift Lock] setting Lower Row For QWERTY or QWERTZ keyboard Upper Row...
  • Page 68 2564 Barcode Scanner User Guide Capital Lock Capital Lock State Description Capital Lock OFF Assuming that the status of Caps Lock on the keyboard is OFF, transmitted characters are exactly the same as in the barcode (when "case-sensitive" is selected for Alphabets Transmission).
  • Page 69 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Refer to 5.1 Letter Case. Digits Transmission By default, the alphanumeric keypad is used for transmitting digits. Select “Numeric Keypad” if you wish to use the keys on the numeric keypad. Numeric Key *Alphanumeric Key Update...

  • Page 70: Inter-Character Delay

    2564 Barcode Scanner User Guide Note: If you select “Numeric Keypad”, the Num Lock status of the physical keyboard should be “ON”. This setting is not supported on PDAs. Kanji Transmission Kanji Transmission is supported by the scanner when either Bluetooth HID, Keyboard Wedge via the cradle or USB HID via the cradle is selected for the output interface.

  • Page 71: Inter-Function Delay

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.1.5 INTER-FUNCTION DELAY By default, the inter-function delay is set to zero. Specify a value, ranging from 0 to 254 in units of millisecond, to match the computer response time of the keyboard interface. Such delay time is inserted between every function code (0x01 ~ 0x1F) being transmitted.

  • Page 72: Special Keyboard Feature

    2564 Barcode Scanner User Guide 2.1.7 SPECIAL KEYBOARD FEATURE By default, this interface employs special function codes (0x01 ~ 0x1F) defined in the Keyboard Wedge Table. However, users may want to get rid of these special codes within the barcodes to avoid data error. You can decide whether to apply the special keyboard feature.

  • Page 73: Simple Pairing For Iphone/Ipad

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Normal *Fast 2.1.10 SIMPLE PAIRING FOR IPHONE/IPAD The window requiring pairing passcode is always pop-up when you are using a ® Bluetooth connection to an iPhone or iPad. To connect to iOS-based devices more ®...

  • Page 74: Utf8 Conversion

    2564 Barcode Scanner User Guide Auto reconnect on data being scanned Auto reconnect off 2.1.13 UTF8 CONVERSION This function, disabled by default, is only for Russian, Cyrillic, Armenian, and Thai keyboard types. Enable *Disable Enter Setup...

  • Page 75: Bt Spp Slave

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.2 BT SPP SLAVE For BT SPP Slave, refer to Chapter 3 Setting up a WPAN Connection for related connection settings. 2.2.1 ACTIVATE BT SPP SLAVE MODE Scan this barcode to have the scanner get into SPP Slave Mode.

  • Page 76: Bt Spp Slave Hardware Flow Control

    2564 Barcode Scanner User Guide 2) Read the “Decimal Value” barcode on page 251. For example, read “1” and “0” for the scanner to automatically shut down after being idle for 1 second. 3) Read the “Validate” barcode on the same page to complete this setting.

  • Page 77: Bt Spp Master

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.3 BT SPP MASTER As a SPP master device, the scanner will be able to resume connection with the host upon powering on again, as long as the host application is running. If the scanner fails to resume connection, it will try every 5 seconds to re-connect to the host unless you have the scanner read the “Reset Connection”...
  • Page 78 The example below is a 2D barcode containing codes ‘#@CipherLab’, ‘88686471166254’ (Set Connection), ‘0x’ (Prefix to the target MAC ID), and ‘00D0176F0030’ (MAC ID of the target device). Underlining the digits is to make them more readable.

  • Page 79: Inter-Function Delay

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь #@CipherLab Enter Setup Set connection 88686471166254 Prefix to the target MAC ID MAC address ID of the target device 00d0176f0030 The concatenation of setup barcodes can be combined to create a single 2D barcode as below:...

  • Page 80: Ack/Nak Timeout

    2564 Barcode Scanner User Guide 2.3.3 ACK/NAK TIMEOUT By default, the scanner sends data to the host without waiting for an ACK/NAK response before sending more data. Specify a value, ranging from 1 to 99 in units of 0.1 second. If no response within the specified period of time, the scanner will attempt to send the same data two more times.

  • Page 81: Switch Between Master/Slave Modes

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.3.4 SWITCH BETWEEN MASTER/SLAVE MODES After the scanner has established a connection as a SPP slave device, you may have it read the “Activate BT SPP, Master Mode” setup barcode to switch to SPP Master Mode. This will result in easy and reliable re-connection, just like connecting with the cradle.

  • Page 82: Keyboard Wedge Via Bt Cradle

    2564 Barcode Scanner User Guide 2.4 KEYBOARD WEDGE VIA BT CRADLE The Y cable allows you to connect the scanner via the cradle to the keyboard input port of PC and you may join the keyboard as well. The scanned data will be transmitted to the host keyboard port as if it is manually entered via the keyboard.

  • Page 83: Activate Keyboard Wedge & Select Keyboard Type

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.4.1 ACTIVATE KEYBOARD WEDGE & SELECT KEYBOARD TYPE When Keyboard Wedge interface is activated, you have to select a keyboard type to complete this setting. Activate Keyboard Wedge &...

  • Page 84: Keyboard Settings

    2564 Barcode Scanner User Guide PS55 002-2, 003-2 PCAT (Thai) 2.4.2 KEYBOARD SETTINGS  Alphabets Layout Digits Layout  Capital Lock Type  Capital Lock Setting  Alphabets Transmission  Digits Transmission   Kanji Transmission Alternate Composing  Laptop Support ...
  • Page 85 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь US Keyboard Style – Normal QWERTY layout, which is normally used in western countries.  Select “Lower Row” for the “Digits Layout” setting because the upper row is for special characters.
  • Page 86 2564 Barcode Scanner User Guide Digits Layout Select a proper layout that matches Alphabets Layout settings. The scanner will make adjustments according to this setting. Options Description Normal Depends on the [Shift] key or [Shift Lock] setting Lower Row For QWERTY or QWERTZ keyboard...
  • Page 87 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Capital Lock Type & Setting In order to send the alphabets with correct case, the scanner needs to know the status of Caps Lock on the keyboard. Incorrect settings may result in reversed case of the alphabets being transmitted.
  • Page 88 2564 Barcode Scanner User Guide *Capital Lock OFF Alphabets Transmission By default, the alphabets transmission is case-sensitive, meaning that the alphabets will be transmitted according to their original case, the status of Caps Lock on the keyboard, as well as the Capital Lock setting.
  • Page 89 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Digits Transmission By default, the alphanumeric keypad is used for transmitting digits. Select “Numeric Keypad” if wishing to use the keys on the numeric keypad. Numeric Key *Alphanumeric Key Note: If selecting “Numeric Keypad”, the Num Lock status of the physical keyboard...

  • Page 90: Inter-Character Delay

    2564 Barcode Scanner User Guide ALT Composing By default, Alternate key composing is disabled. Select [Yes] to allow emulating Alternate key code of a specific keyboard character. For example, [Alt] + [065] will be sent to host for the character “A”...

  • Page 91: Inter-Function Delay

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.4.4 INTER-FUNCTION DELAY By default, the inter-function delay is set to zero. Specify a value, ranging from 0 to 254 in units of millisecond, to match the computer response time of the keyboard interface. Such delay time is inserted between every function code (0x01 ~ 0x1F) being transmitted.

  • Page 92: Via Bt Cradle

    2564 Barcode Scanner User Guide 2.5 RS-232 VIA BT CRADLE Use the RS-232 cable to connect the scanner to the serial port of PC and join the power adaptor to the RS-232 connector. The associated RS-232 parameters must match those configured on the computer.

  • Page 93: Data Bits

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2400 bps 1200 bps 600 bps 2.5.3 DATA BITS *8 bits 7 bits 2.5.4 PARITY *No parity Even 2.5.5 STOP BIT 2 stop bits *1 stop bit Update...

  • Page 94: Flow Control

    2564 Barcode Scanner User Guide 2.5.6 FLOW CONTROL By default, there is no flow control in use. Select the flow control (handshake) method. Options Description No flow control Scanner Ready The scanner will activate the RTS signal upon powering on. After each good read, the scanner will then wait for the CTS signal to become active.

  • Page 95: Inter-Character Delay

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.5.7 INTER-CHARACTER DELAY By default, the inter-character delay is zero. Specify a value, ranging from 0 to 254 in units of millisecond, to match the computer response time. Such delay time is inserted between every character being transmitted.

  • Page 96: Ack/Nak Timeout

    2564 Barcode Scanner User Guide 2.5.9 ACK/NAK TIMEOUT By default, the scanner sends data to the host without waiting for an ACK/NAK response before sending more data. Specify a value, ranging from 1 to 99 in units of 0.1 second. If no response within the specified period of time, the scanner will attempt to send the same data two more times.

  • Page 97: Usb Hid Via Bt Cradle

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.6 USB HID VIA BT CRADLE For USB HID, use the USB cable to connect the scanner via cradle to the USB port of PC and connect the power supply cord.

  • Page 98: Activate Usb Hid & Select Keyboard Type

    2564 Barcode Scanner User Guide 2.6.1 ACTIVATE USB HID & SELECT KEYBOARD TYPE With the USB HID interface activated, you have to select a keyboard type to complete this setting. Activate Direct USB HID & Select Keyboard Type… 1) Read the barcode above to activate USB HID and select a keyboard type.

  • Page 99: Keyboard Settings

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.6.2 KEYBOARD SETTINGS Alphabets Layout  Digits Layout  Capital Lock Type  Capital Lock Setting  Alphabets Transmission   Digits Transmission Kanji Transmission ...
  • Page 100 2564 Barcode Scanner User Guide US Keyboard Style – Normal QWERTY layout, which is normally used in western countries.  Select “Lower Row” for the “Digits Layout” setting because the upper row is for special characters. French Keyboard Style – AZERTY French layout;...
  • Page 101 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Digits Layout Select a proper layout that matches the alphabets layout. The scanner will make adjustments according to this setting. Options Description Normal Depends on the [Shift] key or [Shift Lock] setting Lower Row For QWERTY or QWERTZ keyboard Upper Row...
  • Page 102 2564 Barcode Scanner User Guide Capital Lock Type & Setting In order to send the alphabets with correct case, the scanner needs to know the status of Caps Lock on the keyboard. Incorrect settings may result in reversed case of the alphabets being transmitted.
  • Page 103 Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь *Capital Lock OFF Alphabets Transmission By default, the alphabets transmission is case-sensitive, meaning that the alphabets will be transmitted according to their original case, the status of Caps Lock on the keyboard, as well as the Capital Lock setting.
  • Page 104 2564 Barcode Scanner User Guide Digits Transmission By default, the alphanumeric keypad is used for transmitting digits. Select “Numeric Keypad” to use the keys on the numeric keypad. Numeric Key *Alphanumeric Key Note: If selecting “Numeric Keypad”, the Num Lock status of the physical keyboard should be "ON".

  • Page 105: Inter-Character Delay

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.6.3 INTER-CHARACTER DELAY By default, the inter-character delay is set to zero. Specify a value, ranging from 0 to 254 in units of millisecond, to match the computer response time of the keyboard interface.

  • Page 106: Hid Character Transmit Mode

    2564 Barcode Scanner User Guide 2.6.5 HID CHARACTER TRANSMIT MODE By default, HID interface sends data to the host character by character. You may have the scanner read the “Batch Processing” barcode to process data in batch. Batch Processing *By Character Note: “By Character”...

  • Page 107: Utf8 Conversion

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Auto reconnect off 2.6.8 UTF8 CONVERSION This function, disabled by default, is only for Russian, Cyrillic, Armenian, and Thai keyboard types. Enable *Disable 2.6.9 USB POLLING INTERVAL Scan the barcodes below to specify the USB polling interval ranging from 1 to 15ms.

  • Page 108: Usb Virtual Com Via Bt Cradle

    2564 Barcode Scanner User Guide 2.7 USB VIRTUAL COM VIA BT CRADLE Use the USB cable to connect the scanner via cradle to the USB port of PC and connect the power supply cord. You may run HyperTerminal.exe on your computer, and the scanned data will be transmitted to the computer.

  • Page 109: Ack/Nak Timeout

    Chapter 2 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 2.7.4 ACK/NAK TIMEOUT By default, the scanner sends data to the host without waiting for an ACK/NAK response before sending more data. Specify a value, ranging from 1 to 99 in units of 0.1 second. If no response within the specified period of time, the scanner will attempt to send the same data two more times.

  • Page 110: Usb Vcom Via Cradle Auto-Reconnection

    2564 Barcode Scanner User Guide 2.7.5 USB VCOM VIA CRADLE AUTO-RECONNECTION Users can decide whether to have the scanner automatically reconnect to a paired device after disconnection, and the occasion for reconnecting. *Auto reconnect immediately Auto reconnect on data scanned...

  • Page 111: Setting Up A Wpan Connection

    Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Chapter 3 SETTING UP A WPAN CONNECTION The scanner can be configured to send data to a host computer wirelessly via the cradle, ® or to a notebook computer or PDA with Bluetooth wireless technology.

  • Page 112: Connecting Via Cradle

    2564 Barcode Scanner User Guide 3.1 CONNECTING VIA CRADLE By default, the interface of the cradle is set to “USB HID”. Use the interface cable to connect the scanner via cradle to PC. You can have up to seven scanners connected to one computer at the same time.

  • Page 113: Change Interface

    Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 3.1.2 CHANGE INTERFACE If you want to change the interface cable of the cradle, use one of the scanners to configure the interface-related settings and it will pass the new settings to the cradle, which will then initialize and pass the settings to any other connected scanners.

  • Page 114: Configure Related Settings

    2564 Barcode Scanner User Guide 3.1.3 CONFIGURE RELATED SETTINGS Sniff Mode (Power-saving) By default, this feature is enabled, meaning the scanner will listen to the wireless network at a reduced rate. *Enable Disable 3.2 CONNECTING VIA BLUETOOTH DONGLE ® 3.2.1 CHANGE INTERFACE Below is the procedure to configure the scanner before establishing a WPAN connection ®...

  • Page 115: Configure Related Settings

    Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 3.2.2 CONFIGURE RELATED SETTINGS Sniff Mode (Power-saving) By default, this feature is enabled, meaning the scanner will listen to the wireless network at a reduced rate. *Enable Disable Note: When connecting more than two scanners to a notebook computer or PDA with...
  • Page 116 2564 Barcode Scanner User Guide 1) Read the barcode above to configure the device name. 2) Read the “Hexadecimal Value” barcode on page 252 for the desired character string. 3) Read the “Validate” barcode to complete this setting. Enter Setup...
  • Page 117 Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Authentication When any changes are made to authentication and PIN code on the scanner side, you will have to remove the scanner from the paired device list (called unpairing) and go through the whole process to re-establish the connection.
  • Page 118 2564 Barcode Scanner User Guide Use random PIN No PIN required Note: When using BT HID, some device driver may not support pre-defined PIN code for authentication. In this case, make sure you have the scanner set to “No PIN or use random PIN”...

  • Page 119: Connect To Dongle

    Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 3.2.3 CONNECT TO DONGLE The procedure goes through associating devices for establishing a WPAN connection, which is pretty much the same except for the software you are using. If your computer is ®...
  • Page 120 2564 Barcode Scanner User Guide Turn on the scanner with correct WPAN settings, such as select BT SPP or BT HID, broadcasting enabled, authentication enabled, and PIN code specified, etc. Select the check box of [My device is set up and ready to be found] on your computer.
  • Page 121 Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Wait for a few seconds for the Wizard to search available devices nearby. The scanner will appear with its “serial number” as the device name. You may double-check the “Serial Number”...
  • Page 122 2564 Barcode Scanner User Guide Click [Next]. Enter the passkey for authentication, which must be exactly the same as configured for the scanner. Enter Setup...
  • Page 123 Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Click [Next]. Wait for a few seconds for Windows to exchange passkeys. Update...
  • Page 124 2564 Barcode Scanner User Guide Note: When Bluetooth security is enabled without providing a pre-set PIN code, dynamic input of PIN code is supported. Click [Finish]. 2564 as BT SPP Slave 2564 as BT SPP Master Enter Setup...
  • Page 125 Chapter 3 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Now the target scanner will be listed as shown below. You can have up to seven scanners connected to one computer at the same time. Select and Remove Note: When any changes are made to authentication and PIN code on the scanner side, or you want to change to use BT HID, it is suggested that you remove the scanner...
  • Page 126 2564 Barcode Scanner User Guide BT SPP Connected BT SPP Disconnected Enter Setup...

  • Page 127: Changing Symbology Settings

    Chapter 4 CHANGING SYMBOLOGY SETTINGS In this chapter, a brief on the symbology settings is provided for reference. Users can simply scan the setting barcodes below to disable/enable all symbologies. Enable Disable Settings for each particular symbology will be depicted as follows. IN THIS CHAPTER 4.1 Codabar ..............

  • Page 128: Codabar

    2564 Barcode Scanner User Guide 4.1 CODABAR *Enable Disable 4.1.1 SECURITY LEVEL Security Level renders more decoding accuracy giving consideration to barcodes’ print quality. The scanner allows you to change the CODABAR security level between high or normal level. *Normal High 4.1.2 START/STOP TRANSMISSION...

  • Page 129: Start/Stop Character Selection

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.1.3 START/STOP CHARACTER SELECTION Select one of the four different start/stop character pairs – * abcd/abcd abcd/tn*e ABCD/ABCD ABCD/TN*E 4.1.4 CLSI CONVERSION When enabled, the CLSI editing strips the start/stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar barcode.

  • Page 130: Code Length Qualification

    2564 Barcode Scanner User Guide 4.1.5 CODE LENGTH QUALIFICATION To prevent the "short scan" error, define the "Length Qualification" settings to ensure that the correct barcode is read by qualifying the allowable code length. If "Max/Min Length" is selected, the maximum length and the minimum length must ...

  • Page 131: Code 25 - Industrial 25

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.2 CODE 25 – INDUSTRIAL 25 *Enable Disable 4.2.1 SELECT START/STOP PATTERN This decides the readability of all 2 of 5 symbology variants. For example, flight tickets actually use an Industrial 2 of 5 barcode but with Interleaved 2 of 5 start/stop pattern.

  • Page 132: Transmit Check Digit

    2564 Barcode Scanner User Guide 4.2.3 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit Industrial 25 Check Digit Do Not Transmit 4.2.4 CODE LENGTH QUALIFICATION To prevent the "short scan" error, define the "Length Qualification" settings to ensure that the correct barcode is read by qualifying the allowable code length.
  • Page 133 Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Max. Length (*127) or Fixed Length 1 Min. Length (*4) or Fixed Length 2 3) Read the “Decimal Value” barcode on page 251 for the desired length. 4) Read the “Validate”...

  • Page 134: Code 25 - Interleaved 25

    2564 Barcode Scanner User Guide 4.3 CODE 25 – INTERLEAVED 25 *Enable Disable 4.3.1 SELECT START/STOP PATTERN This decides the readability of all 2 of 5 symbology variants. For example, flight tickets actually use an Industrial 2 of 5 barcode but with Interleaved 2 of 5 start/stop pattern. In order to read this barcode, the start/stop pattern selection parameter of Industrial 2 of 5 should set to "Interleaved 25".

  • Page 135: Transmit Check Digit

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.3.3 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit Interleaved 25 Check Digit Do Not Transmit 4.3.4 CODE LENGTH QUALIFICATION To prevent the "short scan"...
  • Page 136 2564 Barcode Scanner User Guide Max. Length (*126) or Fixed Length 1 Min. Length (*4) or Fixed Length 2 3) Read the “Decimal Value” barcode on page 251 for the desired length. 4) Read the “Validate” barcode on the same page to complete this setting.

  • Page 137: Code 25 - Matrix 25

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.4 CODE 25 – MATRIX 25 Enable *Disable 4.4.1 SELECT START/STOP PATTERN This decides the readability of all 2 of 5 symbology variants. For example, flight tickets actually use an Industrial 2 of 5 barcode but with Interleaved 2 of 5 start/stop pattern.

  • Page 138: Transmit Check Digit

    2564 Barcode Scanner User Guide 4.4.3 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit Matrix 25 Check Digit Do Not Transmit Enter Setup...

  • Page 139: Code Length Qualification

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.4.4 CODE LENGTH QUALIFICATION To prevent the "short scan" error, define the "Length Qualification" settings to ensure that the correct barcode is read by qualifying the allowable code length. If "Max/Min Length"...

  • Page 140: Code 39

    2564 Barcode Scanner User Guide 4.5 CODE 39 *Enable Disable 4.5.1 TRANSMIT START/STOP CHARACTERS Decide whether to verify the check digit. If incorrect, the barcode will not be accepted. Transmit Code 39 Start/Stop Characters *Do Not Transmit 4.5.2 VERIFY CHECK DIGIT Decide whether to verify the check digit.

  • Page 141: Transmit Check Digit

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.5.3 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit Code 39 Check Digit Do Not Transmit 4.5.4 STANDARD/FULL ASCII CODE 39 Decide whether to support Code 39 Full ASCII that includes all the alphanumeric and special characters.

  • Page 142: Asterisks (*) As Data Characters

    2564 Barcode Scanner User Guide 4.5.6 ASTERISKS (*) AS DATA CHARACTERS Decide whether to take asterisk (*) as part of the data. Enable *Disable 4.5.7 CODE LENGTH QUALIFICATION To prevent the "short scan" error, define the "Length Qualification" settings to ensure that the correct barcode is read by qualifying the allowable code length.

  • Page 143: Code 93

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Max. Length (*127) or Fixed Length 1 Min. Length (*4) or Fixed Length 2 3) Read the “Decimal Value” barcode on page 251 for the desired length. 4) Read the “Validate”...
  • Page 144 2564 Barcode Scanner User Guide *Enable Max./Min. Length (1~127)… Enable Fixed Length(s)… 2) Read the barcode for Max. Length or Fixed Length 1, and follow steps 3~4. Repeat steps 2~4 for Min. Length or Fixed Length 2. Max. Length (*127) or Fixed Length 1 Min.

  • Page 145: Code 128

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.7 CODE 128 *Enable Disable 4.7.1 SECURITY LEVEL Security Level renders more decoding accuracy giving consideration to barcodes’ print quality. Decide the security level for reading Code 128 barcodes. *Normal High Update...

  • Page 146: 132

    2564 Barcode Scanner User Guide 4.8 EAN-8 EAN-8 *Enable EAN-8 (No Addon) Disable EAN-8 Addon 2 Enable EAN-8 Addon 2 *Disable EAN-8 Addon 5 Enable EAN-8 Addon 5 *Disable 4.8.1 CONVERT TO EAN-13 Decide whether to expand the read EAN-8 barcode, as well as its addons, into EAN-13.

  • Page 147: Transmit Check Digit

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.8.2 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit EAN-8 Check Digit Do Not Transmit 4.8.3 CONVERSION FORMAT When converting EAN-8 to EAN-13, you can scan the barcode below to decide conversion in default or GTIN-13 format.

  • Page 148: 134

    2564 Barcode Scanner User Guide 4.9 EAN-13 EAN-13 *Enable EAN-13 (No Addon) Disable EAN-13 Addon 2 Enable EAN-13 Addon 2 *Disable EAN-13 Addon 5 Enable EAN-13 Addon 5 *Disable Enter Setup...

  • Page 149: Addon Modes

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.9.1 EAN-13 ADDON MODES Decide whether to enable EAN-13 414/419/434/439 Addon Mode. When enabled, barcodes starting with 414/419/434/439 won’t be decoded if the scanned barcodes do not have the Addon 2 or Addon 5 suffix.
  • Page 150 2564 Barcode Scanner User Guide Decide whether to enable EAN-13 Addon Mode. When enabled, barcodes starting with won’t be decoded if the scanned barcodes do not have the Addon 2 or Addon 5 suffix. EAN-13 978 Addon Mode Enable *Disable Decide whether to enable EAN-13 Addon Mode.

  • Page 151: Convert To Isbn

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Decide whether to enable EAN-13 Addon Mode. When enabled, barcodes starting with won’t be decoded if the scanned barcodes do not have the Addon 2 or Addon 5 suffix.

  • Page 152: Transmit Check Digit

    2564 Barcode Scanner User Guide Convert EAN-13 to ISSN *Do Not Convert 4.9.4 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit EAN-13 Check Digit Do Not Transmit 4.9.5 SECURITY LEVEL Security Level renders more decoding accuracy giving consideration to barcodes’ print quality.

  • Page 153: Gs1-128 (Ean-128)

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.10 GS1-128 (EAN-128) *Enable Disable Note: When this setting is disabled, GS1-128 barcodes used to be taken as Code 128. 4.10.1 TRANSMIT CODE ID Decide whether to include the Code ID (“ ”) in the data being transmitted.

  • Page 154: Gs1 Formatting

    2564 Barcode Scanner User Guide 4.10.3 GS1 FORMATTING Decide whether to enable GS1 formatting for GS1-128. Enable *Disable 4.10.4 APPLICATION ID MARK Decide whether to add an application ID mark (1 character) to the left (AIMark1) or right (AIMark2) of an application ID (AI) for the purpose of labeling it when formatting the GS1 data.

  • Page 155: Isbt 128

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.11 ISBT 128 *Enable Disable 4.11.1 ISBT CONCATENATION Decide whether to decode and concatenate pairs of ISBT barcodes. Auto-discriminate ISBT Concatenation  It decodes and concatenates pairs of ISBT barcodes immediately. If only a single ISBT barcode is present, the scanner must decode 10 times before transmitting its data to confirm that there is no additional ISBT barcode.

  • Page 156: Msi

    2564 Barcode Scanner User Guide 4.12 MSI Enable *Disable 4.12.1 VERIFY CHECK DIGIT Select one of the three calculations to verify check digit(s) when decoding barcodes. If incorrect, the barcode will not be accepted. *Single Modulo 10 Double Modulo 10 Modulo 10 &...

  • Page 157: Code Length Qualification

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.12.3 CODE LENGTH QUALIFICATION To prevent the "short scan" error, define the "Length Qualification" settings to ensure that the correct barcode is read by qualifying the allowable code length. If "Max/Min Length"...

  • Page 158: French Pharmacode

    2564 Barcode Scanner User Guide 4.13 FRENCH PHARMACODE Enable *Disable 4.13.1 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted. *Transmit French Pharmacode Check Digit Do Not Transmit 4.14 ITALIAN PHARMACODE Enable *Disable 4.14.1 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted.

  • Page 159: Plessey

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.15 PLESSEY Enable *Disable 4.15.1 CONVERT TO UK PLESSEY Decide whether to change each occurrence of the character 'A' to character 'X' in the decoded data. Convert to UK Plessey *Do Not Convert 4.15.2 TRANSMIT CHECK DIGIT...

  • Page 160: Gs1 Databar (Rss Family)

    2564 Barcode Scanner User Guide 4.16 GS1 DATABAR (RSS FAMILY) It is categorized into three groups: Group I — GS1 DataBar Omnidirectional (RSS-14)  GS1 DataBar Omnidirectional This group consists of the following:  GS1 DataBar Truncated  GS1 DataBar Stacked ...

  • Page 161: Gs1 Databar Omnidirectional (Rss-14)

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.16.2 GS1 DATABAR OMNIDIRECTIONAL (RSS-14) Enable RSS-14 & RSS Expanded (Groups I, II) *Disable The settings below apply to Group I symbologies only: GS1 DataBar Omnidirectional ...

  • Page 162: Gs1 Databar Expanded (Rss Expanded)

    2564 Barcode Scanner User Guide Do Not Transmit 4.16.3 GS1 DATABAR EXPANDED (RSS EXPANDED) Enable RSS-14 & RSS Expanded (Groups I, II) *Disable The settings below apply to Group II symbologies only: GS1 DataBar Expanded  Transmit Code ID Decide whether to include the Code ID in the data being transmitted.

  • Page 163: Gs1 Databar Limited (Rss Limited)

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.16.4 GS1 DATABAR LIMITED (RSS LIMITED) Enable RSS Limited (Group III) *Disable Transmit Code ID Decide whether to include the Code ID in the data being transmitted. *Transmit RSS Limited Code ID Do Not Transmit...

  • Page 164: Field Separator (Gs Character)

    2564 Barcode Scanner User Guide 4.16.5 FIELD SEPARATOR (GS CHARACTER) Decide whether to apply a field separator (to convert the GS control character to human readable character). Enable Field Separator… 1) Read the barcode above to enable field separator. 2) Read the “Hexadecimal...

  • Page 165: Gs1 Databar Security Level

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.16.8 GS1 DATABAR SECURITY LEVEL Security Level renders more decoding accuracy giving consideration to barcodes’ print quality. Decide the security level for reading GS1 DataBar barcodes. *Normal High 4.17 TELEPEN...

  • Page 166: Telepen Output Ascii/Numeric

    2564 Barcode Scanner User Guide 4.17.1 TELEPEN OUTPUT ASCII/NUMERIC Decide whether to support Telepen in full ASCII code. By default, it supports ASCII mode. AIM Telepen (Full ASCII) includes all the alphanumeric and special characters.  Original Telepen (Numeric) *AIM Telepen...

  • Page 167: Upc-A

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.18 UPC-A UPC-A *Enable UPC-A (No Addon) Disable UPC-A Addon 2 Enable UPC-A Addon 2 *Disable UPC-A Addon 5 Enable UPC-A Addon 5 *Disable Update...

  • Page 168: Convert To Ean-13

    2564 Barcode Scanner User Guide 4.18.1 CONVERT TO EAN-13 Decide whether to expand the read UPC-A barcode, as well as its addons, into EAN-13. After conversion, the data follows EAN-13 format and is affected by EAN-13  programming selections (e.g. Check Digit).

  • Page 169: Upc-E

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.19 UPC-E UPC-E *Enable UPC-E (No Addon) Disable UPC-E Addon 2 Enable UPC-E Addon 2 *Disable UPC-E Addon 5 Enable UPC-E Addon 5 *Disable Update...

  • Page 170: Select System Number

    2564 Barcode Scanner User Guide 4.19.1 SELECT SYSTEM NUMBER Decide whether to decode the ordinary UPC-E barcodes only or both UPC-E0 and UPC-E1 barcodes.  System number enabled for decoding UPC-E0 barcodes. System number enabled for decoding UPC-E1 barcodes. ...

  • Page 171: Transmit System Number

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.19.3 TRANSMIT SYSTEM NUMBER Decide whether to include the system number in the data being transmitted. Transmit UPC-E System Number *Do Not Transmit 4.19.4 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted.

  • Page 172: Code 11

    2564 Barcode Scanner User Guide 4.20 CODE 11 Enable *Disable 4.20.1 VERIFY CHECK DIGIT Select one of the verification when decoding barcodes. If incorrect, the barcode will not be accepted. None Double Single *Auto 4.20.2 TRANSMIT CHECK DIGIT Decide whether to include the check digit in the data being transmitted.

  • Page 173: Security Level

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.20.3 SECURITY LEVEL Security Level renders more decoding accuracy giving consideration to barcodes’ print quality. Decide the security level for reading Code 11 barcodes. Normal *High 4.20.4 CODE LENGTH QUALIFICATION To prevent the "short scan"...
  • Page 174 2564 Barcode Scanner User Guide Max. Length (*127) or Fixed Length 1 Min. Length (*4) or Fixed Length 2 4) Read the “Validate” barcode on the same page to complete this setting. Enter Setup...

  • Page 175: Composite Code

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.21 COMPOSITE CODE 4.21.1 COMPOSITE CC-A/B Decide whether to enable Composite CC-A/B. Enable Composite CC-A/B *Disable Decide whether to enable GS1 formatting for Composite CC-A/B. When enabled, the field separator and application ID mark will be automatically added to the output data.

  • Page 176: Upc Composite Mode

    2564 Barcode Scanner User Guide 4.21.3 UPC COMPOSITE MODE UPC barcodes can be “linked” with a 2D barcode during transmission as if they were one barcode. UPC Never Linked  Transmit UPC barcodes regardless of whether a 2D barcode is detected.

  • Page 177: Symbologies

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.22 2D SYMBOLOGIES 4.22.1 PDF417 *Enable PDF417 Disable 4.22.2 MICROPDF417 Decide whether to enable MicroPDF417 barcodes. Enable MicroPDF417 *Disable 4.22.3 DATA MATRIX Decide whether to enable Data Matrix barcodes. *Enable Data Matrix Disable DATA MATRIX MIRROR...
  • Page 178 2564 Barcode Scanner User Guide *Never Always Auto DATA MATRIX INVERSE Decide whether to decode inverse Data Matrix barcodes. *Never Always Auto GS1 FORMATTING Decide whether to enable GS1 formatting for GS1-Data Matrix barcodes. When enabled, the field separator and application ID mark will be automatically added to the output data.
  • Page 179 Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Specify Field Separator… 1) Read the barcode above to enable field separator. 2) Read the “Hexadecimal System” barcode on page 252 for the desired character string.

  • Page 180: Qr Code

    2564 Barcode Scanner User Guide 4.22.4 QR CODE *Enable QR Code Disable QR CODE MIRROR Decide whether to decode mirror image QR Code barcodes. Never — do not decode QR Code barcodes that are mirror images.  Always — decode only QR Code barcodes that are mirror images.

  • Page 181: Microqr

    Chapter 4 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4.22.5 MicroQR Enable MicroQR *Disable 4.22.6 MAXICODE *Enable Maxicode Disable 4.22.7 AZTEC *Enable Aztec Disable AZTEC MIRROR Decide whether to decode mirror image Aztec barcodes. ...

  • Page 182: Han Xin

    2564 Barcode Scanner User Guide Auto AZTEC INVERSE Decide whether to decode inverse Aztec barcodes. *Never Always Auto 4.22.8 HAN XIN Enable Han Xin *Disable Enter Setup...

  • Page 183: Defining Output Format

    Chapter 5 DEFINING OUTPUT FORMAT Users can configure the data output format in which the collected data will be output to the host computer. Barcodes read by the scanner will be processed in the following sequence – 1) Perform character substitution on the data scanned. 2) Add Code ID Length Code...

  • Page 184: Character Substitution

    2564 Barcode Scanner User Guide 5.2 CHARACTER SUBSTITUTION Character substitution is performed on every occurrence of the first character specified. If only one character is specified, each time the character occurs in the barcode will be taken away.  The first character will be replaced by the second character(s).

  • Page 185: Select A Set For Character Substituion

    Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 5.2.1 SELECT A SET FOR CHARACTER SUBSTITUION Configure Set 1 Configure Set 2 Configure Set 3 1) Read the barcode above to enable character substitution by set. For example, have the scanner read the “Set 1”...

  • Page 186: Symbologies For Character Substitution (All 3 Sets)

    2564 Barcode Scanner User Guide 5.2.2 SYMBOLOGIES FOR CHARACTER SUBSTITUTION (ALL 3 SETS) By default character substitution will be performed on all symbologies. If the character substitution is not desired with one or more symbologies, read the “Do Not Apply”...
  • Page 187 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Character Substitution for GS1-128 *Apply Do Not Apply Character Substitution for ISBT 128 *Apply Do Not Apply Character Substitution for EAN-8 (No Addon) *Apply Do Not Apply Character Substitution for EAN-8 Addon 2 *Apply Do Not Apply...
  • Page 188 2564 Barcode Scanner User Guide Character Substitution for EAN-13 (No Addon) *Apply Do Not Apply Character Substitution for EAN-13 Addon 2 *Apply Do Not Apply Character Substitution for EAN-13 Addon 5 *Apply Do Not Apply Character Substitution for French Pharmacode...
  • Page 189 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Character Substitution for Industrial 25 *Apply Do Not Apply Character Substitution for Interleaved 25 *Apply Do Not Apply Character Substitution for Matrix 25 *Apply Do Not Apply Character Substitution for MSI *Apply Do Not Apply...
  • Page 190 2564 Barcode Scanner User Guide Character Substitution for GS1 DataBar *Apply Do Not Apply Character Substitution for Telepen *Apply Do Not Apply Character Substitution for UPC-A (No Addon) *Apply Do Not Apply Character Substitution for UPC-A Addon 2 *Apply Do Not Apply...
  • Page 191 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Character Substitution for UPC-E (No Addon) *Apply Do Not Apply Character Substitution for UPC-E Addon 2 *Apply Do Not Apply Character Substitution for UPC-E Addon 5 *Apply Do Not Apply Character Substitution for Code 11...
  • Page 192 2564 Barcode Scanner User Guide Character Substitution for Comopsite CC-C *Apply Do Not Apply Character Substitution for PDF417 *Apply Do Not Apply Character Substitution for MicroPDF417 *Apply Do Not Apply Character Substitution for Data Matrix *Apply Do Not Apply Character Substitution for Maxicode...
  • Page 193 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Character Substitution for QR Code *Apply Do Not Apply Character Substitution for MicroQR *Apply Do Not Apply Character Substitution for Aztec *Apply Do Not Apply Character Substitution for Han Xin *Apply Do Not Apply...

  • Page 194: Prefix/Suffix Code

    2564 Barcode Scanner User Guide 5.3 PREFIX/SUFFIX CODE By default, there is no prefix code, and [ENTER] or [CR] (Carriage Return) is configured to be suffix code. Up to 8 characters can be configured, for example, “Barcode_”, and have the string appear in front of the barcode read, like this – “Barcode_1234567890”.

  • Page 195: Code Id

    Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 5.4 CODE ID Up to two characters for Code ID can be configured for each symbology. To make the Code ID configuration easier, the scanner provides five pre-defined Code ID sets that can select one and make necessary changes on it.

  • Page 196: Select Pre-Defined Code Id

    2564 Barcode Scanner User Guide 5.4.1 SELECT PRE-DEFINED CODE ID Apply Code ID Set 1 Apply Code ID Set 2 Apply Code ID Set 3 Apply Code ID Set 4 Apply Code ID Set 5 Enter Setup...
  • Page 197 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Code ID options Set 1 Set 2 Set 3 Set 4 Set 5 Code 39 Italian Pharmacode French Pharmacode Industrial 25 Interleaved 25 Matrix 25 Codabar Code 93 Code 128...
  • Page 198 2564 Barcode Scanner User Guide *Disable AIM Code ID After applying AIM Code ID, three characters are added in front of the output data. “]” is always the first character. The second (Character) and third (Modifier Character) may vary depending on symbologies. Please refer to the table below.
  • Page 199 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Plessey No options specified. Always transmit 0. Industrial 25 No options specified. Always transmit 0. Telepen No options specified. Always transmit 0. UPC/EAN 0: Standard data packet in full EAN format (13 digits for EAN-13, UPC-A, and UPC-E;...

  • Page 200: Change Code Id

    2564 Barcode Scanner User Guide 5.4.2 CHANGE CODE ID 1) Read the barcode below to change code ID of a specific symbology. 2) Read the “Hexadecimal Value” barcode on page 252 for the desired character string. For example, read “4” and “4” for applying the character [D] for Code ID.
  • Page 201 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Configure Code ID for Interleaved 25 Configure Code ID for Matrix 25 Configure Code ID for Configure Code ID for Plessey Configure Code ID for Telepen Configure Code ID for UPC-A...

  • Page 202: Clear Code Id Settings

    2564 Barcode Scanner User Guide Configure Code ID for Data Matrix Configure Code ID for Maxicode Configure Code ID for QR Code Configure Code ID for MicroQR Configure Code ID for Aztec Configure Code ID for Han Xin 5.4.3 CLEAR CODE ID SETTINGS...

  • Page 203: Length Code

    Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 5.5 LENGTH CODE A 4-digit code representing the length of barcode data (character count) can be inserted in front of data being transmitted. Such "Length" code can be individually enabled or disabled for each symbology.
  • Page 204 2564 Barcode Scanner User Guide Length Code for GS1-128 & GS1 DataBar Apply *Do Not Apply Length Code for ISBT 128 Apply *Do Not Apply Length Code for EAN-8 Apply *Do Not Apply Length Code for EAN-13 Apply *Do Not Apply...
  • Page 205 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Length Code for Italian Pharmacode Apply *Do Not Apply Length Code for Industrial 25 Apply *Do Not Apply Length Code for Interleaved 25 Apply *Do Not Apply Length Code for Matrix 25 Apply *Do Not Apply...
  • Page 206 2564 Barcode Scanner User Guide Length Code for Pleesey Apply *Do Not Apply Length Code for Telepen Apply *Do Not Apply Length Code for UPC-A Apply *Do Not Apply Length Code for UPC-E Apply *Do Not Apply Length Code for Code 11...
  • Page 207 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Length Code for Composite CC-A/B Apply *Do Not Apply Length Code for Composite CC-C Apply *Do Not Apply Length Code for PDF417 Apply *Do Not Apply Length Code for MicroPDF417 Apply *Do Not Apply...
  • Page 208 2564 Barcode Scanner User Guide Length Code for Maxicode Apply *Do Not Apply Length Code for QR Code Apply *Do Not Apply Length Code for MicroQR Apply *Do Not Apply Length Code for Aztec Apply *Do Not Apply Length Code for Han Xin...

  • Page 209: Multi-Barcode Editor

    Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 5.6 MULTI-BARCODE EDITOR The Multi-Barcode Editor allows deciding the output sequence of a concatenation of barcodes. Up to five barcodes can be specified. Enabling this mode will force the scanner to apply Laser mode as the scan mode.

  • Page 210: Edit A Concatenation Of Barcodes

    2564 Barcode Scanner User Guide 5.6.1 EDIT A CONCATENATION OF BARCODES Edit Output Sequence 1) Read the barcode above to start editing a concatenation of barcodes. 2) Code Type setting – read the “Hexadecimal Value” barcode on page 252 for Code Type of the (first) barcode.
  • Page 211 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Code Type Symbology Code Type Symbology 3E (>) Han Xin 40 (@) ISBT 128 41 (A) Code 39 42 (B) Italian Pharmacode 43 (C) French Pharmacode 44 (D) Industrial 25 45 (E)

  • Page 212: Activate The Concatenation Of Barcodes

    2564 Barcode Scanner User Guide Note: If not reading 0000 for any length, the 4-digit length must exclude prefix, suffix (0x0d by default), length code, etc. 4) Matching Character setting – read the “Hexadecimal Value” barcode on page 252 for the 1 character that must be found matching in the (first) barcode.
  • Page 213 Chapter 5 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь *Ignore Output Sequence Enforce Output Sequence Apply Output Sequence Warning: When disable the Multi-Barcode Editor later, the scan mode remains unchanged. If Laser mode is not desired, proceed to select a scan mode best suits the application.

  • Page 214: Removal Of Special Character

    2564 Barcode Scanner User Guide 5.7 REMOVAL OF SPECIAL CHARACTER Specify only 1 character, but it will remove every matching character encountered from the starting position of barcode data until a different character is met. For example, if it is configured to remove the character “0” (hex value is “30”), one or more zeros will be stripped off the barcode data “012345”...

  • Page 215: Applying Formats For Data Editing

    Chapter 6 APPLYING FORMATS FOR DATA EDITING The scanner allows advanced data editing by applying user-configured editing formats. The whole processed data can be divided into fields by user-specified rules. These fields together with the user-configurable additional fields consist of the data actually sent to the host computer.

  • Page 216: Activating Editing Formats

    2564 Barcode Scanner User Guide 6.1 ACTIVATING EDITING FORMATS 6.1.1 ACTIVATE EDITING FORMATS Any editing format configured before can directly be applied. If there’s not, users must start with configuring an editing format first, and then activate the editing format when it is desired in use.

  • Page 217: Exclusive Data Editing

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Editing Format 5 Enable *Disable 6.1.2 EXCLUSIVE DATA EDITING By default, only barcodes found meeting with the criteria are processed by the editing formats. Those found not meeting with the criteria are processed normally. When “Exclusive Data Editing”...

  • Page 218: How To Configure Editing Formats

    2564 Barcode Scanner User Guide 6.2 HOW TO CONFIGURE EDITING FORMATS End Programming Format...

  • Page 219: Select Format To Configure

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 6.2.1 SELECT FORMAT TO CONFIGURE Start Programming Format Select one editing format (Format 1~5) and the parameters pertaining to the editing format can then be configured – applicable code type, data length, matching string & location, start position, field adjustment, total number of fields, field settings (field-dividing rule), additional fields, and field transmission sequence.

  • Page 220: Restore Default Format

    2564 Barcode Scanner User Guide 6.2.2 RESTORE DEFAULT FORMAT Select an existing editing format and have the defaults restored. The default settings of an editing format are listed below. Editing format Defaults Applicable Code Type Data Length 0 (No qualification)

  • Page 221: Configuring Format - Define Data Criteria

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 6.3 CONFIGURING FORMAT — DEFINE DATA CRITERIA Three applicable conditions can be configured to check whether the data read by the scanner can be processed by the particular editing format. Note: Data editing cannot be performed unless the three conditions are all met.
  • Page 222 2564 Barcode Scanner User Guide Editing Format for Codabar *Apply Do Not Apply Editing Format for Code 39 *Apply Do Not Apply Editing Format for Code 93 *Apply Do Not Apply Editing Format for Code 128 *Apply Do Not Apply Editing Format for GS1-128 &...
  • Page 223 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Editing Format for ISBT 128 *Apply Do Not Apply Editing Format for EAN-8 *Apply Do Not Apply Editing Format for EAN-8 Addon 2 *Apply Do Not Apply Editing Format for EAN-8 Addon 5 *Apply Do Not Apply...
  • Page 224 2564 Barcode Scanner User Guide Editing Format for EAN-13 Addon 2 *Apply Do Not Apply Editing Format for EAN-13 Addon 5 *Apply Do Not Apply Editing Format for French Pharmacode *Apply Do Not Apply Editing Format for Italian Pharmacode *Apply...
  • Page 225 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Editing Format for Interleaved 25 *Apply Do Not Apply Editing Format for Matrix 25 *Apply Do Not Apply Editing Format for MSI *Apply Do Not Apply Editing Format for Plessey *Apply Do Not Apply...
  • Page 226 2564 Barcode Scanner User Guide Editing Format for UPC-A *Apply Do Not Apply Editing Format for UPC-A Addon 2 *Apply Do Not Apply Editing Format for UPC-A Addon 5 *Apply Do Not Apply Editing Format for UPC-E *Apply Do Not Apply...
  • Page 227 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Editing Format for UPC-E Addon 5 *Apply Do Not Apply Editing Format for Code 11 *Apply Do Not Apply Editing Format for Composite CC-A/B *Apply Do Not Apply Editing Format for Composite CC-C *Apply...
  • Page 228 2564 Barcode Scanner User Guide Editing Format for MicroPDF417 *Apply Do Not Apply Editing Format for Data Matrix *Apply Do Not Apply Editing Format for Maxicode *Apply Do Not Apply Editing Format for QR Code *Apply Do Not Apply Editing Format for MicroQR...
  • Page 229 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Editing Format for Aztec *Apply Do Not Apply Editing Format for Han Xin *Apply Do Not Apply Update...

  • Page 230: Data Length

    2564 Barcode Scanner User Guide 6.3.2 DATA LENGTH The length must include prefix, suffix (0x0d by default), length code, etc. By default, barcodes of any length (character count) are eligible for data editing. Specify a value.  When zero is given to both, the scanner will not perform the length qualification.
  • Page 231 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 4) Read the barcode to specify the location of the matching string. Location of Matching String… 5) Read the “Decimal Value” barcode on page 251 for the desired location. 6) Read the “Validate”...

  • Page 232: Configuring Format - Define Data Field

    2564 Barcode Scanner User Guide 6.4 CONFIGURING FORMAT — DEFINE DATA FIELD 6.4.1 START POSITION Data can be divided into fields in one of the following direction – from head (F1) to tail (F5)   from tail (F1) to head (F5)

  • Page 233: Total Number Of Fields

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 6.4.3 TOTAL NUMBER OF FIELDS Data can be divided into at most 6 fields; each of them is numbered from F1 to F6 accordingly. However, only F1~F5 can be configured. The total number of fields must be specified correctly.

  • Page 234: Field Settings

    2564 Barcode Scanner User Guide 6.4.4 FIELD SETTINGS Data eligible for editing formats is divided into fields by user-specified rules – either using the field terminating string or specified field length. By Terminating String Specify the field terminating string. Up to two characters are allowed. The scanner will search for the occurrence of this particular string in the data.
  • Page 235 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Field 2 Setting Read the barcode below to divide field 2 by a specified terminating string. Select Field Separator to Divide Field 2… Read the “Hexadecimal Value”...
  • Page 236 2564 Barcode Scanner User Guide Field 3 Setting Read the barcode below to divide field 3 by a specified terminating string. Select Field Separator to Divide Field 3… Read the “Hexadecimal Value” barcode on page 252 for the desired character string.
  • Page 237 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Field 4 Setting Read the barcode below to divide field 4 by a specified terminating string. Select Field Separator to Divide Field 4… Read the “Hexadecimal Value”...
  • Page 238 2564 Barcode Scanner User Guide Field 5 Setting Read the barcode below to divide field 5 by a specified terminating string. Select Field Separator to Divide Field 5… Read the “Hexadecimal Value” barcode on page 252 for the desired character string.
  • Page 239 Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь Additional Fields Up to five additional fields can be created for each editing format; each of them is numbered from AF1 to AF5 accordingly.  If “Keyboard Wedge”...

  • Page 240: Pause Field Setting

    2564 Barcode Scanner User Guide 6.4.5 PAUSE FIELD SETTING Pause Field Time Limit the pause time interval (1~16). By default, it is set to 1 second. Pause Field Time 1~16 sec. (*1) Read the barcode above to specify the time interval for the Pause Field. (It is set to 1 by default.)

  • Page 241: Configuring Format - Define Transmission Sequence

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 6.5 CONFIGURING FORMAT — DEFINE TRANSMISSION SEQUENCE After configuring the data fields and additional fields, you must now program the transmission sequence of these fields that comprise the final data. This field transmission sequence can be assigned in any desired order and fields can be assigned multiple times as well.
  • Page 242 2564 Barcode Scanner User Guide Additional Field 2 Additional Field 3 Additional Field 4 Additional Field 5 Pause Field Null Character Field 3) Read the “End” barcode to complete this setting. End Programming… End Programming Format...

  • Page 243: Programming Examples

    Chapter 6 Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь 6.6 PROGRAMMING EXAMPLES 6.6.1 EXAMPLE I Extract data from the 10th character to the 19th character... The editing format should be configured as follows: Read the “Enter Setup” barcode to enter the Configuration Mode. Read the “Configure Format 1”...

  • Page 244: Example Ii

    2564 Barcode Scanner User Guide 6.6.2 EXAMPLE II Extract the date code, item number, and quantity information from barcodes. Data in a barcode is encoded like this:  From the 1 character to the 6 character is the date code.

  • Page 245: Specifications

    SPECIFICATIONS Optical Characteristics 2564 Scan Engine 2D Imager Light Source Aiming pattern: 620~630nm LED Illumination: Warm White LED RF Characteristics WPAN Module Wireless PAN BT Class 2 compliance Coverage (line-of-sight) 100 meters with the cradle  Serial Port Profile (BT SPP) Interface Supported ...
  • Page 246 2564 Barcode Scanner User Guide Electrical Characteristics Battery Rechargeable Li-ion battery – 3.7 V, 800 mAh Power Adaptor Input AC 100~240 V, 47/63 Hz Output DC 5V, 1A Operating Temperature 0 °C to 40 °C Environmental Characteristics Temperature Operating 0 °C to 50 °C Storage -40 °C to 70 °C...

  • Page 247: Firmware Upgrade

    Appendix I FIRMWARE UPGRADE You can only upgrade firmware of one scanner at a time. For example, you must turn off each of the rest scanners when there is more than one scanner connected to your computer. Note: In case it fails downloading due to low battery, make sure the targe scanner is loaded with good battery and the battery charge is enough.
  • Page 248 2564 Barcode Scanner User Guide Enter Setup Activate Cradle USB Virtual COM Update 5) Read the following barcodes in sequence for the scanner to enter the download mode. The scanner will respond with beeps to indicate it is ready for downloading.

  • Page 249: Using Bluetooth ® Dongle

    Appendix I Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображаться. Note: The output interface remains unchanged as specified in step 2 (= RS-232 or USB Virtual COM). For RS-232, the baud rate setting is still 115200 bps! USING BLUETOOTH DONGLE ®...
  • Page 250 2564 Barcode Scanner User Guide Kernel Program User Program K2564_V*.shx STD2564_V*.shx  communication settings, select “RS-232” and the correct COM port for BT SPP interface.  For RS-232, select 115200 bps for baud rate; for USB Virtual COM, ignore the baud rate setting.

  • Page 251: How To Upgrade Bt Cradle Firmware

    Appendix I Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здесь отображаться. HOW TO UPGRADE BT CRADLE FIRMWARE 1) Connect the interface cable, RS-232 or USB, between the cradle and your computer. For USB Virtual COM, you may need to install its driver first! 2) Connect the power supply cord from the cradle to a proper power outlet.
  • Page 252 2564 Barcode Scanner User Guide 6) Run the download utility “ProgLoad.exe” on your computer. Kernel Program User Program 2564CradleKV*.shx 2564CradleUV*.shx  communication settings, select “RS-232” and the correct COM port for RS-232 or USB Virtual COM interface.  For RS-232, select 115200 bps for baud rate;...

  • Page 253: Host Serial Commands

    Appendix II HOST SERIAL COMMANDS SERIAL COMMANDS Purpose To disable the scanner. Remarks “D” Purpose To enable the scanner. Remarks “E” #@ nnnnnn <CR> Purpose To configure the scanner. Remarks nnnnnn – the six digits of command parameters. For example, “109952” is to list the current Code ID settings. List Page 3 Serial Command “0x23”...
  • Page 254 2564 Barcode Scanner User Guide #@TRIGOFF<CR> Purpose To disable the software trigger Remarks “0x23” + “0x40” + “0x54” + “0x52” + “0x49” + “0x47” + “0x4f” + “0x46” + “0x46” + “0x0d” #@TRIGON<CR> Purpose To enable the software trigger Remarks “0x23”...

  • Page 255: Example

    Appendix II Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес For example, ‘#@GLED,09’ is to have the scanner blink for 9 times. “0x23” + “0x40” + “0x47” + “0x4c” + “0x45” + “0x44” + “0x2c” + “0x30” + “0x39”...
  • Page 256 2564 Barcode Scanner User Guide Note: (1) For RS-232 or USB Virtual COM, you can only configure the first scanner that connects to the cradle. To identify the scanner, you may send the serial command to have it respond with a beep.

  • Page 257: Bt Cradle Setup Barcodes & Serial Commands

    Appendix II Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес BT CRADLE SETUP BARCODES & SERIAL COMMANDS Normally, you can configure the cradle stand by having a connected scanner read cradle-related setup barcodes. 1) Connect the interface cable, RS-232, Keyboard Wedge or USB, between the cradle and your computer.

  • Page 258: Bt Cradle Serial Command And Equivalent Setup Barcodes

    2564 Barcode Scanner User Guide BT CRADLE SERIAL COMMAND AND EQUIVALENT SETUP BARCODES Config<CR> Purpose To configure the cradle. Here is the setup barcode for this serial command: Config Remarks A list of the current settings will be displayed. Run HyperTerminal.exe on your computer and change the settings one by one.
  • Page 259 Appendix II Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес USB. Here is the setup barcode for this serial command: UseVariablePort Version<CR> Purpose To get the firmware versions. Here is the setup barcode for this serial command: Version GetID<CR>...

  • Page 260: Example

    2564 Barcode Scanner User Guide EXAMPLE Without using the scanner to read the above setup barcodes for configuring the cradle, you may run HyperTerminal.exe on the host computer to send serial commands to the cradle via RS-232 or USB. 1) Connect the interface cable, RS-232 or USB, between the cradle and your computer.

  • Page 261: Keyboard Wedge Table

    Appendix III KEYBOARD WEDGE TABLE The table below features special keyboard wedge codes applied to the scanner by default. If you have determined to bypass this special keyboard, please refer to the table on the next page. “Apply” Special Keyboard ...
  • Page 262 2564 Barcode Scanner User Guide “Bypass” Special Keyboard " & < > Enter Setup...

  • Page 263: Key Type & Status

    Appendix III Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде KEY TYPE & STATUS KEY TYPE If “Keyboard Wedge” or “USB HID” is configured for interface, Key Type and Key Status will then become applicable. *Normal Scan Code KEY STATUS...

  • Page 264: Example

    2564 Barcode Scanner User Guide EXAMPLE KEY TYPE = NORMAL For example, if you want to program the character “!” as the prefix code: Read the “Configure Prefix” barcode. Read the “Hexadecimal Value” barcode on page 252 for “2” and “1”.

  • Page 265: Numeral Systems

    Appendix IV NUMERAL SYSTEMS DECIMAL SYSTEM Decimal Validate the Values Validate Update Abort...

  • Page 266: Hexadecimal System

    2564 Barcode Scanner User Guide HEXADECIMAL SYSTEM Hexadecimal Enter Setup...
  • Page 267 Appendix IV Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде Validate the Values Validate Update Abort...

  • Page 268: Ascii Table

    2564 Barcode Scanner User Guide ASCII TABLE " & < > Enter Setup...

  • Page 269: Entering Pin Code For Authentication

    Appendix IV Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде ENTERING PIN CODE FOR AUTHENTICATION USE PRESET PIN 1) In the configuration mode, read the barcode below to use a preset PIN for authentication. Use Preset PIN 2) Read one of the barcodes to specify the PIN code, in decimal or hexadecimal.

  • Page 270: Disable Authentication Or Use Random Pin

    2564 Barcode Scanner User Guide DISABLE AUTHENTICATION OR USE RANDOM PIN In the configuration mode, read the barcode below to disable authentication (= No PIN) or use a random PIN for authentication. *No PIN or use random PIN Note: When using BT HID, some device driver may not support pre-defined PIN code for authentication.

  • Page 271: Reading Driver Licenses

    Appendix V READING DRIVER LICENSES The scanner is capable of reading 2D driver’s licenses and other American Association of Motor Vehicle Administrators (AAMVA) compliant ID cards. For compliant 2D licensed card scanning, it decodes the information embedded in the ID cards to a formatted data. This appendix provides the setup barcodes required while ScanMaster utility provides GUI setup that is oganized and easy-to-use.

  • Page 272: Output Sequence Setup

    2564 Barcode Scanner User Guide OUTPUT SEQUENCE SETUP The scanner supports arranging the sequences of license embedded data via separators and fields. In order to present data in a consistent format, some barcodes (ex. First Name, Middle Name/Initial, Last Name, Name suffix, Name Prefix, Birth Date and so on) will return data based on the calculated actual data contained in the ID barcode.
  • Page 273 Appendix V Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес Mailing Address Postal Code Home Address Line1 Home Address Line2 Home Address City Home Address State Home Address Postal Code License ID Number License Class License Restrictions License...
  • Page 274 2564 Barcode Scanner User Guide Weight (Pounds) Weight (Kilograms) Eye Color Hair Color License Expiration Date Birth Date Gender License Issue Date Issue Timestamp Number of Duplicates Medical Codes Organ Donor Enter Setup...
  • Page 275 Appendix V Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес Nonresident Customer ID Social Security Number AKA Birth Date AKA Social Security Name AKA Full Name AKA Last Name AKA First Name AKA Middle Name/Initial AKA Name Suffix AKA Name Prefix Weight Range...
  • Page 276 2564 Barcode Scanner User Guide Document Discriminator Country Federal Commission Codes Place of Birth Audit Information Inventory Control Race/Ethnicity Std Vehicle Class Std Restrictions Std Endorsements Class Description Endorsement Description Enter Setup...
  • Page 277 Appendix V Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес Restrictions Description Permit Class Permit Expiration Date Permit ID Number Permit Issue Date Permit Restrictions Permit endorsements Issuer ID Number Family Name Truncation First Name Truncation Middle Name Truncation...

  • Page 278: Separators And Fields

    2564 Barcode Scanner User Guide SEPARATORS AND FIELDS Define the separators that separate fields during the transmission sequence of data scanning. In addition to the built-in data elements, you can also specify up to 5 Additional Fields with 4 bytes characters. Program the transmission sequence by reading the desired fields as additional fields.

  • Page 279: Edit Separators

    Appendix V Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен здес EDIT SEPARATORS All the driver license fields can be split with a pre-selected separator, for example, “-” as First Name-Last Name or “:” as First Name:Last Name. Edit Separator 1 Edit Separator 2 Edit Separator 3...

  • Page 280: Edit Fields

    2564 Barcode Scanner User Guide EDIT FIELDS Up to five additional fields can be created for each editing format; each of them is numbered from Additional 1 to Additional 5 accordingly.  ® If “Bluetooth HID” or “USB HID” is configured for interface, Key Type and Key Status will then become applicable.

  • Page 281: Keyboard Type One-Scan Barcode

    Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде Appendix VI KEYBOARD TYPE ONE-SCAN BARCODE BLUETOOTH HID PCAT (US) PCAT (French) PCAT (German) PCAT (Italian) PCAT (Swedish) PCAT (Norwegian) PCAT (UK) PCAT (Belgium) Update Abort...
  • Page 282 2564 Barcode Scanner User Guide PCAT (Spanish) PCAT (Portuguese) PS55 A01-2 (Japanese) User-defined table PCAT (Turkish) PCAT (Hungarian) PCAT (Swiss German) PCAT (Danish) PCAT (Russian) Enter Setup...
  • Page 283 Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде PCAT (Cyrillic on Russian) PCAT (Armenian) PCAT (Thai) Update Abort...
  • Page 284 2564 Barcode Scanner User Guide KEYBOARD WEDGE (CRADLE) PCAT (US) PCAT (French) PCAT (German) PCAT (Italian) PCAT (Swedish) PCAT (Norwegian) PCAT (UK) PCAT (Belgium) PCAT (Spanish) Enter Setup...
  • Page 285 Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде PCAT (Portuguese) PS55 A01-1 PS55 A01-2 (Japanese) PS55 A01-3 PS55 001-1 PS55 001-81 PS55 001-2 PS55 001-82 PS55 001-3 Update Abort...
  • Page 286 2564 Barcode Scanner User Guide PS55 001-8A PS55 002-1, 003-1 PS55 002-81, 003-81 PS55 002-2, 003-2 PS55 002-82, 003-82 PS55 002-3, 003-3 PS55 002-8A, 003-8A IBM 3477 Type 4 (Japanese) PS2-30 Enter Setup...
  • Page 287 Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде IBM 34XX/319X, Memorex Telex 122 Keys User-defined table PCAT (Turkish) PCAT (Hungarian) PCAT (Swiss German) PCAT (Danish) PCAT (Russian) PCAT (Cyrillic on Russian) PCAT (Armenian) Update Abort...
  • Page 288 2564 Barcode Scanner User Guide PCAT (Thai) Enter Setup...
  • Page 289 Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде REMOTE USB HID (CRADLE) PCAT (US) PCAT (French) PCAT (German) PCAT (Italian) PCAT (Swedish) PCAT (Norwegian) PCAT (UK) PCAT (Belgium) PCAT (Spanish) Update Abort...
  • Page 290 2564 Barcode Scanner User Guide PCAT (Portuguese) PS55 A01-2 (Japanese) User-defined table PCAT (Turkish) PCAT (Hungarian) PCAT (Swiss German) PCAT (Danish) PCAT (Russian) PCAT (Cyrillic on Russian) Enter Setup...
  • Page 291 Appendix VI Ошибка! Используйте вкладку "Главная" для применения Heading 1 к тексту, который должен зде PCAT (Armenian) PCAT (Thai) Update Abort...

Table of Contents
