I
NSTRUCTIONS FOR TROUBLESHOOTING COMMON COMPONENT ERRORS
FIGURE 9. Troubleshoot Nexus Station load/unload sensor errors
FIGURE 10. DIP-switch settings for the Nexus Station front-load sensor
Outgoing carrier not detected at back sensor
See the instructions for troubleshooting the error, "Arriving carrier not detected at back sensor."
APR/2017
| C
ARRIER AND SENSOR ERRORS
Set a lower threshold to decrease sensitivity; set a
higher threshold to increase sensitivity of the sensor.
Factory default setting
TECHNICAL OPERATIONS AND MAINTENANCE GUIDE |
Loosen screws to remove sensor board
DIP switches
NEXUS STATION
