LEANING PROCEDURES LEAN BEHIND THE CORE
2
Wipe down the area beneath the air filter, including the sides and bottom of the station, as well as
under the rim of the base frame.

Clean behind the core-turnstile assembly

If you discover evidence or have reason to believe that the station has been substantially contaminated by a
larger spill, removing the core-turnstile assembly from the station may become necessary. Follow the
instructions elsewhere in this guide for setting up the rails and trolley from the Nexus Station One-Person
Installation Kit to help you remove the core-turnstile assembly from the station.
1
Follow the instructions in this guide to remove the turnstile assembly from the station.
turnstile assembly" on page 50.
2
After pulling the core-turnstile assembly forward from the station, leave it hanging over the front of
the station with the trolley in a locked position as you clean the outer turnstile assembly and the sta-
tion walls.
3
Clean the side and back walls lower portion of the station that were not accessible with the turnstile
assembly in place.
Wipe down the walls. floor, divider, and both sides of the rim of the base frame
APR/2017
-
TURNSTILE ASSEMBLY
TECHNICAL OPERATIONS AND MAINTENANCE GUIDE |
70
See "Core-
