Nexus Station rear view

The next mechanical drawing shows the back of the Nexus station. Although this drawing shows a retrofit-
ted station, the components are also the same as those in newly installed Nexus Station housing.
FIGURE 4. Nexus station rear view
NEXUS STATION | TECHNICAL OPERATIONS AND MAINTENANCE GUIDE
S | N S
TATION DESIGN EXUS TATION REAR VIEW
Storage-panel bracket
Rotary air valve
Top air manifold
Rear carrier sensor
Bypass air tube
Rear air manifold
Push actuator
Turnstile motor
