Drip Container; Door-Bearing Assembly - Swisslog Nexus Technical Operations And Maintenance Manual

M | D
ECHANICAL PARTS RIP CONTAINER
Nexus Station filter assemblies
Back filter

Drip container

The drip container is a plastic bucket that sits below the turnstile to catch possible spills. It is removed and
cleaned as needed and can be replaced when necessary.
TABLE 9. Drip container
Part Number Description
91214501 Drip container and lid
Nexus Station drip container

Door-bearing assembly

Four bearing assemblies hold in place the outer rods allowing movement of the security door. Replace the
full assembly when the bearing wears out.
TABLE 10. Bearing assemblies
Part Number Description
56746801 Bearing assembly
Nexus Station door-bearing assembly
APR/2017
Base filter
TECHNICAL OPERATIONS AND MAINTENANCE GUIDE |
Door filter
Recommended maintenance
Clean or replace as needed
Recommended maintenance
Replace when needed
26
NEXUS STATION
