COPIER > ADJUST > CCD
100DF-RG
Color displacement (R and G lines) correction value in the
vertical scanning direction at ADF reading (100%)
Details
To correct the color displacement (R and G lines) in the
vertical scanning direction at 100% ADF reading.
When replacing the Main Controller PCB, enter the value
of service label.
Use case
When replacing the Main Controller PCB
Adj/set/operate method Enter the setting value (switch negative/positive by -/+
key) and press OK key.
Caution
After the setting value is changed, write the changed
value in the service label.
Display/adj/set range
-512 to 512
Unit
0.001 line
Default value
-333
Supplement/memo
100% reading: 600 dpi in horizontal scanning direction x
600 dpi in vertical scanning direction reading mode.
100DF-GB
Color displacement (G and B lines) correction value in the
vertical scanning direction at ADF reading (100%)
Details
To correct the color displacement (G and B lines) in the
vertical scanning direction at 100% ADF reading.
When replacing the Main Controller PCB, enter the value
of service label.
Use case
When replacing the Main Controller PCB
Adj/set/operate method Enter the setting value (switch negative/positive by -/+
key) and press OK key.
Caution
After the setting value is changed, write the changed
value in the service label.
Display/adj/set range
-512 to 512
Unit
0.001 line
Default value
333
Supplement/memo
100% reading: 600 dpi in horizontal scanning direction x
600 dpi in vertical scanning direction reading mode.
OFST-BW0
Adjustment of CIS (Rear) at B&W reading
Details
To adjust the offset of the CIS (Rear) when reading B&W
original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>BW-AGC
8
Service Mode > COPIER > ADJUST > CCD
M82 M85
8
Service Mode > COPIER > ADJUST > CCD
COPIER > ADJUST > CCD
OFST-BW1
Adjustment of CIS (Center) at B&W reading
Details
To adjust the offset of the CIS (Center) when reading
B&W original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>BW-AGC
OFST-BW2
Adjustment of CIS (Front) at B&W reading
Details
To adjust the offset of the CIS (Front) when reading B&W
original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>BW-AGC
OFST-CL0
Adjustment of CIS (Rear) at color reading
Details
To adjust the offset of the CIS (Rear) when reading color
original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>CL-AGC
OFST-CL1
Adjustment of CIS (Center) at color reading
Details
To adjust the offset of the CIS (Center) when reading
color original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>CL-AGC
OFST-CL2
Adjustment of CIS (Front) at color reading
Details
To adjust the offset of the CIS (Front) when reading color
original.
Use case
When replacing the CIS Unit
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range
0 to 255
Default value
8
Related service mode
COPIER>FUNCTION>CCD>CL-AGC
8-12
M82 M85
