Test Print

Engine test print

The engine test print is to check normal operation of the device.
Print the engine test chart in the following steps.
• MF8500 series
1) Detach the right cover. Refer to page 4-20.
2) Turn on the device on standby to press the test print switch [1] on the right side of the
device.
6
Trouble Shooting > Test Print > Engine test print
F-6-1
6
Trouble Shooting > Test Print > Engine test print
3) The engine test chart is printed in the horizontal line patterns on a sheet as shown below.
6-2
F-6-2
6-2
