Verify the Drive Backplane

2. Reconnect the drive backplane power cable to the drive backplane (2).
3. Reconnect the drive backplane auxiliary power and signal cable to the drive
backplane (4).
Reconnect the SAS cables and the NVMe card cables to the drive backplane (5).
4.
5. Reinstall all of the storage drives into the storage drive cage.
See "Install a Drive" on page
6. Install the disk cage cover.
7. Install all four fan modules.
See "Install a Fan Module" on page
8. Return the server to operation.
See "Returning the Server to Operation" on page
Related Information
"Remove the Drive Backplane" on page 127
■

Verify the Drive Backplane

At the Oracle ILOM prompt, start the fault management shell.
1.
-> start /SP/faultmgmt/shell
Are you sure you want to start /SP/faultmgmt/shell (y/n)? y
faultmgmtsp>
2.
Type fmadm faulty to check for faults.
If faults are reported, see
■
If no faults are reported, then the drive backplane has been replaced
■
successfully.
Related Information
"Remove the Drive Backplane" on page 127
■
132 SPARC S7-2 Server Service Manual • March 2017
56.
65.
145.
"Detecting and Managing Faults" on page 21 .
