Remove the Motherboard

Remove the Motherboard
Caution -
backs up the Oracle ILOM configuration of the service processor. For more information,
see the "Back Up the Oracle ILOM Configuration Settings" section in the Oracle ILOM
Documentation Library at
z400371a1482122.html#scrolltoc.
This is a cold-service procedure that must be performed by qualified service personnel. Power

down the server completely before performing this procedure.

1.

Prepare for servicing.

See "Preparing for Service" on page
Remove the air baffle from the motherboard and set it aside.
2.
Remove these reusable components.
3.
a. Fan modules.
See
Power supplies.
b.
See
c. PCIe risers and attached PCIe cards.
See
d. NVMe and SAS HBA cables.
See
Cables" on page
136 SPARC S7-2 Server Service Manual • March 2017
Use the Oracle ILOM backup utility prior to removing the motherboard. This utility
https://docs.oracle.com/cd/E37444_01/html/E37446/
"Remove a Fan Module" on page
"Remove a Power Supply" on page
"Servicing PCIe Cards" on page
"Remove the HBA SAS Cable Assembly" on page 119
122.
33.
63.
70.
87.
and "Remove the NVMe
