Fan Module LEDs

Fan Module LEDs
Status Indicator
Name
FM Status
Related Information
"Preparing for Service" on page 33
■
"Detecting and Managing Faults" on page 21
■
62 SPARC S7-2 Server Service Manual • March 2017
Color State Meaning
■ Off – The fan module is correctly installed and operating within
Off/Amber
specification.
■ Amber – The fan module is faulty. The front TOP FAN LED and the
front and rear panel Service Required LEDs are also lit if the system
detects a fan module fault.
