Oracle SPARC S7-2 Service Manual page 146

Replace the Top Cover
Note -
the left side (viewing the server from the front). There is also a latch on the underside of the
cover in the front left corner.
3. Check both sides of the chassis to ensure that the four corners of the top cover
are fully down and flush with the chassis.
If the cover corners are not flush with the chassis, slide the cover towards the rear of the chassis
until you can position the cover correctly.
Caution -
toward the front of the chassis, the internal latch that is located on the underside of the cover
might be damaged.
Gently slide the cover toward the front of the chassis until it locks into place
4.
(with an audible click) (2).
As you slide the cover toward the front of the server, watch the green release button. You will
hear an audible click when the green release button pops up, indicating that the cover is locked.
Close the server fan door.
5.
Remove the antistatic precautions.
6.
Related Information
"Remove the Top Cover" on page 49
■
"Return the Server to the Normal Operating Position" on page 147
■
146 SPARC S7-2 Server Service Manual • March 2017
There are three latching tabs on the sides of the cover, two on the right side and one on
If the top cover is not correctly positioned before you attempt to slide the cover
