Servicing Power Supplies

The server has redundant hot-serviceable power supplies. You can remove and replace a power
supply without shutting the server down, provided that the other power supply is online and
working. For information about power configuration policies, refer to the administration guide
and the Oracle ILOM documentation.
"Power Supply LEDs" on page 69
■
"Remove a Power Supply" on page 70
■
"Install a Power Supply" on page 72
■
Related Information
"Remove the Cable Management Arm" on page 42
■

Power Supply LEDs

Each power supply contains two status indicators (LEDs) on the back panel. This figure and
table provide a description of the power supply status indicators.
Note -
detects a power supply fault. See
Components" on page
The front and rear panel Service Required LEDs are also lit when the server
13.
"Front Panel Components" on page 11 and "Rear Panel
Servicing Power Supplies 69
