Remove a Drive

Legend LED
1 OK to Remove
2 Service Required
3 OK/Activity
Remove a Drive
This is a hot-service procedure that can be performed by a customer while the server is running.
Caution -
which can cause server components to fail. Follow safety procedures to
Damage" on page
Determine which drive is faulty by checking the front of the drives for a lit amber
1.
fault LED.
See "Front Panel Components" on page 11
If required, shut down the OS to replace the drive.
2.
Shut down the OS if the drive:
Contains the OS, and the OS is not mirrored on another drive.
■
Cannot be logically isolated from the online operations of the server.
■
To shut down the drive, see
Take the drive offline.
3.
52 SPARC S7-2 Server Service Manual • March 2017
Color State and Meaning
Blue ■ Steady on – The storage drive can be removed safely during a hot-plug
operation.
■ Off – The storage drive has not been prepared for removal.
Amber ■ Off – The storage drive is operating normally.
■ Steady on – The system has detected a fault with the storage drive.
Green ■ Off – Power is off or the installed drive is not recognized by the system.
■ Steady on – The drive is engaged and is receiving power.
■ Steady blink – There is disk activity. The LED blinks on and off to show
activity.
This procedure requires that you handle components that are sensitive to ESD
41.
"Power Off the Server" on page 38
for the locations of the drives in the server.
and go to
"Prevent ESD
Step 5.
