Remove a Fan Module

This is a hot-service procedure that can be performed by a customer while the server is running.
Do not remove a fan without installing a replacement fan to ensure adequate cooling
Caution -
and maintain server availability.
1. Prepare for servicing.
See "Preparing for Service" on page
2. Extend the server to the maintenance position.
See "Extend the Server to the Service Position" on page
3. To open the server fan door, slide the fan door latches to the front of the server
and swing the door up to the open position.
Close the server fan door within 60 seconds to maintain adequate airflow to properly
Caution -
cool the server. Leaving the door open for more than 60 seconds, while the server is running,
might cause the server to overheat and shut down.
Identify the faulty fan module by locating the fan with the amber fault LED lit.
4.
See "Fan Module LEDs" on page
Remove the faulty fan module.
5.
33.
41.
62.
Remove a Fan Module
Servicing Fan Modules 63
