1.5 Product Specifications

Product
Hardware Specifications
Copper Ports
SFP Ports
SFP+ Ports
PoE Injector Ports
Console
Reset Button
Connector
Alarm
Digital Input (DI)
Digital Output (DO)
Enclosure
Installation
Dimensions (W x D x H)
Weight
Power Requirements
Power Consumption
ESD Protection
Surge Protection
LED Indicator
IGS-6329-8UP2S2X
8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
2 1000BASE-SX/LX/BX SFP slot interfaces (Port-9 and Port-10)
Compatible with 100BASE-FX and 2500BASE-X SFP
2 10GBASE-SR/LR SFP+ slot
interfaces (Port-11 to Port-12)
Compatible with 1000BASE-X and
2500BASE-X SFP
8 ports with 802.3bt PoE++ injector function with Port-1 to Port-8
1 x RJ45-to-RS232 serial port (115200, 8, N, 1)
< 5 sec: System reboot
> 5 sec: Factory default
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
Removable 6-pin terminal block for DI/DO interface
Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND
One relay output for power failure. Alarm relay current carry ability: 1A @ 24V
DC
2 digital inputs:
Level 0: -24~2.1V (±0.1V)
Level 1: 2.1~24V (±0.1V)
Input load to 24V DC, 10mA max.
2 digital outputs:
Open collector to 24VDC, 100mA
IP30 aluminum case
DIN-rail or wall mounting
76 x 135 x 152 mm
1,152g
Dual DC 48~54V, 8A max.
(>52V DC for 802.3bt PoE++ output recommended)
Max. 12.9 watts/44.2BTU@54V DC
input (System on)
Max. 415.6 watts/1425.9BTU@54V
DC input (Full loading with 802.3bt
PoE++ function)
Air 8KV DC
Contact 6KV DC
4KV DC
System:
Power 1 (Green), Power 2 (Green), Alarm (Red)
Ring (Green), Ring Owner (Green), DIDO (Red)
Per 10/100/1000T RJ45 PoE++ Port:
1000Mbps LNK/ACT (Green)
10/100Mbps LNK/ACT (Amber)
802.3bt PoE++-in-use x 1 (Green)
24
IGS-6329-8UP2S4X
4 10GBASE-SR/LR SFP+ slot
interfaces (Port-11 to Port-14)
Compatible with 1000BASE-X and
2500BASE-X SFP
1,619g
Max. 12.4 watts/42.3BTU@54V DC
input (System on)
Max. 430 watts/1467.2BTU@54V DC
input (Full loading with 802.3bt
PoE++ function)
