Servicing The Zs3-4 Controller; Replacing A Zs3-4 Hdd Or Ssd - Oracle ZFS Storage Appliance Service Manual

Servicing the ZS3-4 Controller

Be sure to read sections
"Prerequisites for Servicing Hardware" on page
Most hardware faults clear after replacing the affected component. If a fault does not self-clear,
see "Repairing Active Problems" on page
Oracle DE2-24s and Sun Disk Shelves can be used together with standalone and clustered
controllers after certain hardware modifications. Contact Oracle Service to upgrade your
controllers for disk shelf interoperability.
To service ZS3-4 hardware components, use the following tasks.
"Replacing a ZS3-4 HDD or SSD" on page 89
■
"Replacing a ZS3-4 Fan Module" on page 91
■
"Replacing a ZS3-4 Power Supply" on page 93
■
"Replacing a ZS3-4 DIMM" on page 95
■
"Replacing a ZS3-4 PCIe Card or Riser" on page 104
■
"Replacing a ZS3-4 Battery" on page 108
■
To understand the ZS3-4, see the following topics:
"ZS3-4 Base Configuration" on page 111
■
"ZS3-4 Specifications" on page 111
■
"ZS3-4 Front and Rear Panel Components" on page 112
■
"ZS3-4 Internal Components" on page 116
■
"ZS3-4 PCIe I/O Cards" on page 121
■
"ZS3-4 Attached Storage" on page 125
■

Replacing a ZS3-4 HDD or SSD

HDDs and SSDs are hot-swappable and can be removed and installed while the storage
controller is running without affecting other hardware capabilities. Use the following procedure
"Getting Started with Servicing the Hardware" on page 15
49.
37.
and
Servicing the ZS3-4 Controller 89
