7120 Controller Hardware Overview

7120 Base Configuration

The following table shows the configuration options for a 7120 controller. All PCIe cards are
low-profile, and must be fitted with low-profile mounting brackets.
This table describes base configurations for the 7120 with Aura Logzilla.
TABLE 43
Mktg Part Number
TA7120-12TB
TA7120-24TB
The following table describes base configurations for the 7120 with Logzilla 3.5" SSD.
TABLE 44
Mktg Part Number
7101282
7101284

7120 Chassis Overview

The Sun ZFS Storage 7120 is an enterprise-class two-socket rackmount x64 system powered
by the Intel Xeon processor. It packs high performance and room for growth with four PCIe
slots and 18 DIMM slots into a compact 2U footprint. Refer to the product site at
oracle.com/storage/nas/index.html
Refer to the white paper Implementing Fibre Channel SAN Boot with Oracle's Sun ZFS Storage
Appliance at
fbsanboot-365291.html
7120.
The 7120 is a standalone controller that consists of an internal SAS-2 HBA providing disk shelf
expansion, write flash acceleration, and 11 x 300GB 15K, 600GB 15K, 1TB 7.2K, 2TB 7.2K,
or 3TB 7.2K hard drive storage. The SAS-2 storage fabric supports a greater number of targets,
greater bandwidth, higher reliability, and bigger scale.
242 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
7120 Standalone Controller Base Configurations for Aura Logzilla
Description
S7120, 1xCPU, 24GB, 12TB
S7120, 1xCPU, 24GB, 24TB
7120 Standalone Controller Base Configurations for Logzilla 3.5" SSD
Description
S7120, 1xCPU, 24GB, 3.3TB
S7120, 1xCPU, 24GB, 6.6TB
http://www.oracle.com/technetwork/articles/servers-storage-admin/
for details on FC SAN boot solutions using the Sun ZFS Storage
for the most recent component specification.
Mfg Part Number
597-0754-01
597-0755-01
Mfg Part Number
7014523
7014525
