Figure Legend
DIMMs
4
ZS3-2 CPU and Memory - The ZS3-2 controller motherboard has 16 slots in two groups that
hold industry-standard DDR3 low voltage (LV) DIMMS.
ZS3-2 Controller CPU and Memory Components
FIGURE 32
All sockets must be occupied by identical DDR3 DIMMs.
Note -
ZS3-2 Controller CPU Descriptions
TABLE 25
Capacity
256GB
USB flash drive
8
CPU 0
D0, D2, D5, D7 (blue)
D1, D3, D4, D6 (white)
ZS3-2 Controller Hardware Overview
CPU 1
D0, D2, D5, D7 (blue)
D1, D3, D4, D6 (white)
Servicing the ZS3-2 Controller
165
