Servicing the Disk Shelves

Be sure to read sections
"Prerequisites for Servicing Hardware" on page
To replace disk shelf components, use the following tasks.
"Replacing a Faulty Disk Shelf Drive" on page 256
■
"Replacing a Disk Shelf Power Supply" on page 259
■
"Replacing a Disk Shelf I/O Module" on page 264
■
"Replacing a Disk Shelf SIM Board" on page 266
■
"Adding a New Disk Shelf" on page 269
■
"Adding a Disk Shelf Cache Device" on page 270
■
To understand disk shelf components, see the following topics.
"Disk Shelf Front and Back Panel Components" on page 272
■
"Disk Shelf Indicators" on page 277
■
"Disk Shelf Drive Locations" on page 284
■
"Disk Shelf Configurations" on page 286
■
"Maximum Number of Disk Shelves per Controller Configuration" on page 289
■
"SAS-2" on page 289
■

Electrostatic Discharge Precautions

Remove all plastic, vinyl, and foam material from the work area.
■
Wear an antistatic wrist strap at all times when handling any CRU.
■
Before handling any CRU, discharge any static electricity by touching a grounded surface.
■
Do not remove a CRU from its antistatic protective bag until you are ready to install it.
■
After removing a CRU from the chassis, immediately place it in an antistatic bag or
■
antistatic packaging.
"Getting Started with Servicing the Hardware" on page 15
49.
and
Servicing the Disk Shelves 255
