Disk Shelf Configurations - Oracle ZFS Storage Appliance Service Manual

Disk Shelf Hardware Overview
FIGURE 79
For Sun Disk Shelf device types and slot details, see
Configurations" on page

Disk Shelf Configurations

The following table describes device types supported for each disk shelf. For cabling
information, see
Guide. For information on disk compatibility, see the
TABLE 49
Shelf
DE2-24P
286 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
Sun Disk Shelf Drive Locations
286.
"Cabinet and Cabling Guidelines" in Oracle ZFS Storage Appliance Cabling
Disk Shelf Configurations
Device Types
Data
20 Data and 1-4 Log
devices
"Disk Shelf
Oracle Systems
Data Slots Cache/Log Slots
0 - 23 none
0 - 19 20 - 23
Handbook.
Notes/
Examples
Fully populated
HDD data devices.
Twenty HDD data
devices and up to
four log devices.
Example slot
configurations:
Slot 20 (Log), Slot
21 (Log), Slot 22
(Log), Slot 23 (Log)
Slot 20 (Log), Slot
21 (Log), Slot 22
