Oracle ZFS Storage Appliance Service Manual page 281

I/O Module Indicators
FIGURE 73
Figure Legend
Fault / Locate indicator
1
Power / OK indicator
2
SAS-2 Port 0
3
Disk Shelf SIM Board Indicators - The following disk shelves have SIM boards:
Sun Disk Shelf
■
The following figure shows the SIM board indicators for the Sun Disk Shelf.
Figure Legend
SAS-2 Port 1
4
SAS-2 Port 2
5
Host port activity indicators
6
Disk Shelf Hardware Overview
Figure Legend
For Oracle service only
7
For Oracle service only
8
Servicing the Disk Shelves 281
