Motherboard: The motherboard is a FRU and includes CPU modules, slots for 18 DIMMs,
■
memory control subsystems, and the service processor (SP) subsystem. The SP subsystem
controls the host power and monitors host system events (power and environmental). The
SP controller draws power from the host 3.3V standby supply rail, which is available
whenever the system is receiving AC input power, even when the appliance is turned off.
Power Distribution Board: The power distribution board is a FRU and distributes main
■
12V power from the power supplies to the rest of the storage controller. It is directly
connected to the paddle board and to the motherboard through a bus bar and ribbon cable. It
also supports a top cover interlock kill switch.
Paddle Board: The paddle board is a FRU and serves as the interconnect between the
■
power distribution board and the fan power boards, hard drive backplane, and I/O board.
Fan Board: The fan boards are FRUs and carry power to the storage controller fan
■
modules. In addition, they contain fan module status LEDs and transfer I2C data for the fan
modules.
Disk Backplane: The hard drive backplane is a FRU and includes the connectors for the
■
hard disk drives, as well as the interconnect for the I/O board, Power and Locator buttons,
and system/component status LEDs. The storage controller has an eight-disk backplane.
Each drive has an LED indicator for Power/Activity, Fault, and OK-to-Remove (not
supported).
The following list contains the replaceable system boards for the 7320 storage controller.
TABLE 38 7320 Controller Replaceable System Boards
Part Number
F541-2883-01
F541-2885-01
F541-4081-01
F511-1489-01
F511-1548-01
F541-4275-02
7320 Replaceable Components - The following list contains all of the replaceable power
distribution, disk, and fan module components of the 7320. Note that power supplies, disks, and
fan modules are hot-pluggable on the storage controller.
TABLE 39 7320 Controller Replaceable Components
Part Number
F300-2233-02
Description
X8 PCIe Riser Card 1U
X16 PCIe Riser Card 1U
RoHS Motherboard and Tray
DB, Power Distribution Board
PCB, 8 Disk 1U Backplane
PCBA, Connector Board, 1U
Description
RoHS 760W Power Supply
7320 Controller Hardware Overview
FRU/CRU
CRU
CRU
FRU
FRU
FRU
FRU
FRU/CRU
CRU
