Sun Disk Shelf Back Panel
FIGURE 69
Figure Legend
Power supply modules with built-in fans. Power supply 0 is on the left and power supply 1 is on the right.
1
Removable SAS Interface Module (SIM) Boards. SIM 0 is on the left, and SIM 1 is on the right.
2

Disk Shelf Indicators

Disk Shelf Front Panel Indicators - The following figures show the front panel indicators.
