ZS3-2 Controller Hardware Overview
TABLE 24
Dimension
Height
Width
ZS3-2 Electrical Specifications - The ZS3-2 controller electrical specifications are listed
below. The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
Two C13 connectors which work on 110-220v outlets
■
Input
Nominal frequencies: 50/60Hz (47 to 63 Hz range)
■
Nominal voltage range: 100 to 120/200 to 240 VAC
■
Maximum current AC RMS: 6.8 A @ 100-120 V / 3.4 A @ 200-240 V
■
AC operating range: 90-264 VAC
■
Output
3.3 VDC STBY: 3.0A
■
+12 VDC: 86.7A
■
Power Dissipation
Max power consumption: 890 W max
■
Max heat output: 3026 BTU/hr
■
Volt-Ampere rating: 908 VA @ 240 VAC, 0.98P.F.
■
ZS3-2 Acoustic Noise Emissions - In compliance with the requirements defined in ISO 7779,
the workplace-dependent noise level of this product is less than 70 db (A).

ZS3-2 Internal Components

The ZS3-2 chassis has the following field replaceable units (FRUs). FRUs are not customer-
serviceable and must be replaced by trained Oracle service technicians.
PCIe Risers - There are three risers per system, each attached to the rear of the
■
motherboard. Each riser supports two PCIe cards (which are customer replaceable units
(CRUs).
162 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
ZS3-2 Controller Physical Specifications
Measurement
3.44 in./87.4 mm
17.52 in./445 mm
Dimension Measurement
Depth 20.25 in./514 mm
Weight 41.23 lb/18.70 kg
