ZS3-2 Controller Hardware Overview

15. When the system has finished booting, log in and set the time using the steps in
the task
Administration Guide, Release
ZS3-2 Controller Hardware Overview
To understand the ZS3-2 hardware, use the following topics.
"ZS3-2 Base Configuration" on page 156
■
"ZS3-2 Front and Rear Panel Components" on page 157
■
"ZS3-2 Specifications" on page 161
■
"ZS3-2 Internal Components" on page 162
■
"ZS3-2 PCIe I/O Cards" on page 169
■
"ZS3-2 Optional Cable Management Arm" on page 170
■
"ZS3-2 Attached Storage" on page 171
■

ZS3-2 Base Configuration

The ZS3-2 controller is an enterprise-class, rackmount x86 system powered by the Intel Xeon
processor. It provides high performance and room for growth with expandable PCIe slots and
16 DIMM slots in a compact 2U footprint.
TABLE 22
CPU
2x8-core, 2.1
GHz
Refer to the product site at
recent component specification.
For information about supported disks and capacities, refer to the
156 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
"Setting Clock Synchronization (BUI)" in Oracle ZFS Storage Appliance
ZS3-2 Controller Features
Memory Read Cache
256GB 1-4 SAS-2 SSDs
16x16GB
512GB
16x32GB
https://www.oracle.com/storage/nas/index.html
OS8.6.0.
Boot Drive
2x2.5-inch
SAS-2
PCIe Slots HBA
2 dedicated; 4 4-port (4x4)
available SAS-2 6Gb/s
external
for the most
Oracle Systems Handbook.
