7120 Controller I/O Components
FIGURE 59
Figure Legend
Top Cover
1
Right Control Panel Light Pipe Assembly
2

7120 NIC/HBA Options

The following table describes NIC/HBA options for the 7120.
TABLE 47 7120 Controller NIC/HBA Options
Mktg Part Number
SG-XPCIESAS-GEN2-Z
Hard Disk Drives
3
Left Control Panel Light Pipe Assembly
4
Description
2-port External Sun Thebe SAS (x4)
HBA, PCIe
7120 Controller Hardware Overview
Mfg Part Number
594-5889-01
