Replacing a ZS3-2 Flash Drive

24. Go to the Maintenance > Hardware screen of the BUI, and click the right-
arrow icon
component. The online icon
25. If a fault does not self-clear, see
Replacing a ZS3-2 Flash Drive
Removing the USB flash drive is a cold-service operation. You must power off the appliance
before you remove the USB. There will be a loss of access to the storage unless the system is in
a clustered configuration.
The USB flash drive is located in the forward-most USB socket at the center rear of the
motherboard, labeled USB 1, near where Riser 2 installs. Use the following procedure to
replace a ZS3-2 flash drive.
1. Power off the storage controller as described in
Controller" on page
2. Extend the controller from the rack as described in
Controller from the Rack" on page
3. Remove the top cover as described in
4. If a PCIe card installed in Riser 2 prevents you from accessing the USB drive,
remove Riser 2.
152 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
on the controller. Then, click Slot to verify the status of the new
should be green.
"Repairing Active Problems" on page
50.
51.
"Powering Off the
"Extending the Storage
"Removing the Top Cover" on page
37.
52.
