6.0 Configuration
Console Mode:
Console Mode is enable by default. Mini USB port acts as a console port.
Data Mode:
USB Data Mode is Disabled by default. If USB Data Mode is selected and there is a desire to
switch it back to Disabled (console mode) via the USB-to-Serial connection to it, the escape
sequence of '+++' may be entered at the Data Baud Rate for which the port is configured.
Storage Mode:
Storage Mode is disable by default. This setting determines device will acts as a USB Mass
Storage disk drive with capacity of 2MB.
© Microhard Systems Inc.
Image 6X: USB Configuration Data Port
CONFIDENTIAL
USB Device Port Mode
For more information about
any of the Data Port field
parameters refer to Section
6.1.6: COM1 and COM2
Configuration.
Values
Console Mode
Data Mode
Storage Mode
NDIS Mode
