Ntp Server Configuration - Microhard Systems Nano IP Series Operating Manual

6.0 Configuration

6.1.4.2 NTP Server Configuration

The Network Time Protocol (NTP) feature may be ENABLED, provided there is an NTP server
available and its IP address or 'name' is entered in the appropriate field.
NTP may be used to
synchronize the time in
the Nano IP Series within
a network to a reference
time source.
Note that if NTP Server Status is ENABLED, the ‗Synchronize with
NTP Server' soft button on the System Configuration menu will be
available for use.
Leave as DISABLED (default) if a server is not available.
IP address or domain name for NTP server (on local LAN or
website (provided that Internet access is available)) is to be entered
in this field if the NTP Server Status is configured as ENABLED.
© Microhard Systems Inc.
Image 6G: Network Configuration, NTP Server Config. Submenu
CONFIDENTIAL
NTP Server Status
Values
Disable
Enable
NTP Server (IP/Name)
Values
0.0.0.0
valid NTP server IP
address or ‗name'
57
