Appendix D: Approved Antennas

Group
Quarter Wave
Rubber Ducky
Transit Antennas
Yagi Antennas
Omni Directional
Changes or modifications not expressly approved by Microhard Systems Inc. could void the
user's authority to operate the equipment. This device has been tested with MCX and Reverse
Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM prod-
ucts, fixed antennas require installation preventing end-users from replacing them with non-
approved antennas. Antennas not listed in the tables must be tested to comply with FCC Section
15.203 (unique antenna connectors) and Section 15.247 (emissions). Please Contact Microhard
Systems Inc. if you need more information.
© Microhard Systems Inc.
Part Number Description
MHS031010 <1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Right Angle
MHS031020 <1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight
MHS031030 <1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Right Angle MHS
MHS031040 <1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight MHS
MHS031050 <1.5dBi, 900MHz 1/4 Wave Antenna MCX Right Angle MHS
MHS031060 <1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight
MHS031000 2dBi, 900MHz Rubber Ducky Antenna RPTNC Swivel
MHS031070 2dBi, 900MHz Rubber Ducky Antenna Reverse SMA Swivel
MHS031080 2dBi, 900MHz Rubber Ducky Antenna Reverse SMA Straight
MHS031210 3dBd, 900 MHz Transit Antenna with Ground Plane
MHS031220 3dBd, 900MHz Transit Antenna No Ground Plane
MHS031230 3dBd, 900MHz Transit Antenna Permanent Mount GP
MHS031240 3dBd, 900MHz Transit Antenna Permanent Mount NGP
Mounts for Transit Antennas have a RPTNC Pigtail
MHS031311 6dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
MHS031431 6.5dBd, 900MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
MHS031501 9dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
MHS031441 10dBd, 900 MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
MHS031451 11dBd, 900 MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
MHS031401 12dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
MHS031411 12dBd, 900MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
MHS031251 3dBd, 900MHz Omni Directional Antenna Antenex, RPTNC Pigtail
MHS031461 3dBd, 900 MHz Omni Directional Antenna Bluewave, RPTNC Pigtail
MHS031321 6dBd, 900MHz Omni Directional Antenna Antenex, RPTNC Pigtail
MHS031471 6dBd, 900 MHz Omni Directional Antenna Bluewave, RPTNC Pigtail
WARNING:
