Microhard Systems Nano IP Series Operating Manual page 105

6.0 Configuration
Select the Authentication Mode: Local (default) or RADIUS&Local.
For the latter selection, RADIUS authentication must be attempted
FIRST; if unsuccessful, THEN Local authentication may be
attempted.
In this field, the IP address of the RADIUS server is to be entered if
RADIUS&Local has been selected as the Authorization Mode.
In this field, the applicable Port number for the RADIUS Server is to
be entered if RADIUS&Local has been selected as the
Authorization Mode.
Normally, a RADIUS Server uses Port 1812 for the authentication
function.
If
RADIUS&Local, obtain the RADIUS Secret for his particular client
from your RADIUS Server Administrator and enter it into this field,
and the following field. (You will also want to obtain the applicable
RADIUS User Name from your RADIUS Server Administrator.)
See above. Re-enter RADIUS Secret in this field.
Amount of time to wait for RADIUS authentication.
© Microhard Systems Inc.
the IP Series' Authorization Mode has been
CONFIDENTIAL
Auth Mode
Values
Local
RADIUS&Local
RADIUS Server IP
Values
Valid RADIUS server IP
address
0.0.0.0
RADIUS Server Port
Values
Applicable RADIUS
Server Port number
1812
RADIUS Secret
set to
Values
Specific RADIUS Server
secret
nosecret
Repeat RADIUS Secret
Values
Specific RADIUS Server
secret
nosecret
RADIUS Timeout
Values
10
1-65535
seconds
105
