Policies - Microhard Systems Nano IP Series Operating Manual

6.0 Configuration
6.1.8.7.1 Policies Configuration
Select the zone which is to be the source of the data traffic. WAN
applies to the wired connection and LAN to the wireless, on all
Nano IP Series units, whether a Master, Repeater, or Remote.
Select the zone which is the intended destination of the data traffic.
WAN applies to the wired connection and LAN to the wireless, on
all Nano IP Series units, whether a Master, Repeater, or Remote.
© Microhard Systems Inc.
Image 6AF: Firewall Configuration, Policies Config. Submenu
CONFIDENTIAL
Source Zone
Values
WAN
LAN
FW
VPN
all
Destination Zone
Values
WAN
LAN
FW
VPN
all
107
