6.0 Configuration
Awake Time (s): Defines how long the unit will
keep awake. If set to 0, the unit will not wakeup
until data is received on the serial or ethernet port.
Valid range in seconds (s) is 0 - 65535.
Sleep Time (s): Defines how long the unit will
sleep. If set to 0, the unit will not enter sleep
mode. Valid range is 0 - 65535 (s).
Refresh Interval (s): Refresh Timer to automati-
cally refresh the web browser.
Save:
Apply Settings:
Reset:
View Unit Sleep Status Only:
Auto Refresh:
© Microhard Systems Inc.
Image 6AY: Remote Sleep Control
Writes values entered in the boxes above to the Master units memory.
Writes values in Master units memory to the remote unit.
Resets values shown in the boxes above to the values stored in the Master unit.
Forces the browser to refresh.
CONFIDENTIAL
Unit Address: Unit Address of the remote
unit where the sleep commands are sent.
Sleep Mode:
No Sleep: No sleep settings.
Radio Sleep: Shuts down radio module
when not in use for the configured amount
of time.. IP/CPU Module is still active dur-
ing radio sleep. Unit will re-sync and
transmit data in ~1 second upon wakeup.
Will wakeup on timer and/or activity.
System Sleep: Shuts down entire unit.
Will wakeup on timer and/or activity. Upon
wake up system will restart and re-sync
and transmit data in ~60 seconds.
Image 6AZ: Remote Sleep Control
Retrieves the sleep settings stored on the remote unit.
Remote Sleep Control
129
