Microhard Systems Nano IP Series Operating Manual page 74

6.0 Configuration
This configuration option does not apply to a Master Nano IP.
On (the default) permits the Nano IP to transmit, i.e. RF emissions
are enabled.
Off configures the Nano IP for RECEIVE ONLY. If ‗Off' is selected,
‗On' may only be selected LOCALLY or via a special UDP packet
sent from the DiscoverIP Utility.
This feature allows a Remote unit to synchronize with a specified ‗upstream' unit (either Master
or Repeater). The options are as follows:
65535: With this value as its Roaming Address, a Remote will synchronize with an upstream
unit which has the same Network Name as the Remote. Should that upstream unit fail, this
Remote will attempt to synchronize with another 'upstream' unit within the same network (i.e.
When bench testing 3 IP
Series for a Master-
same Network Name). This ability is particularly well-suited to mobile applications.
Repeater-Remote link, be
sure to set the Remote's
1-254: In most static (fixed) networks, where there are no Repeaters, the default value of 1 is
Roaming Address to the
maintained: All Slaves synchronize to the Master (whose unit address is 1).
Unit Address (UA) of the
Repeater, and the
Repeater's Roaming
In networks where Repeaters are present, the value of a Remote's
Address to the UA (1) of
Roaming Address typically corresponds to the particular upstream modem with which a
the Master.
particular Remote is intended to communicate, e.g. Slave with Unit Address 3 may have a
This will ensure that data Roaming Address of 2, where the modem with Unit Address 2 is a Repeater between the Slave
is routed from the Remote
and the Master; the Repeater will have a Roaming Address of 1 as it is to synchronize to the
through the Repeater to
Master.
the Master; otherwise, if
the Remote's Roaming
The Roaming Address dictates to which IP Series (by Unit Address (UA)) a Remote (or
Address is left at the
Repeater) will 'look' or 'attach to' for its upstream signal path.
default value of 1, the
Remote will communicate
directly with the Master,
See the description of Network Profile earlier in this section for more information about roaming-
bypassing the Repeater
type options. The Network Profile allows for roaming between networks whereas the Roaming
altogether.
Address provides for roaming within a network.
© Microhard Systems Inc. CONFIDENTIAL
Tx Control
Values
On
Off
Roaming Address
Values
65535 full roaming
1-254 specific (fixed) unit
address (Master or
Repeater) with which to
associate
1
74
