3.0 Hardware Description
3.2.3 Connectors and Indicators
© Microhard Systems Inc.
Pin Name
No.
COM2_RxD
1 Console Port Receive Data. Output from Nano IP to PC
COM2_TxD
3 Console Port Transmit Data. Input from PC to Nano IP
LED_TX
5 Active high output indicating radio is transmitting data over RF channel.
LED_RX
7 Active high output indicating radio receive and synchronization status.
RX+
2 RS485/422 RX+
RX-
4 RS485/422 RX-
TX+
6 RS485/422 TX+
TX-
8 RS485/422 TX-
STATUS_LED
9 System Status Indicator.
GND
11,18 Ground reference for logic, radio, and I/O pins.
ETH_CAT1
13 Ethernet RJ45 Pin 1.
ETH_CAT2
15 Ethernet RJ45 Pin 2.
ETH_CAT3
17 Ethernet RJ45 Pin 3. Optional CAN bus (CAN-)
ETH_CAT6
19 Ethernet RJ45 Pin 6. Optional CAN bus (CAN+)
COM1_CTS
10 Data Port. Clear To Send. Active low output.
COM1_RTS
12 Data Port. Request To Send. Active low input.
COM1_DCD
14 Data Port. Data Carrier Detect. Active low output.
COM1_TxD
16 Data Port. Transmit Data. Output from the modem
COM1_RxD
20 Data Port. Receive Data. Input into the module.
COM1_DSR
22 Data Port. Data Set Ready. Active low output.
COM1_DTR
24 Data Terminal Ready. Active low input.
USB_DP(+)
21 USB device positive data line.
USB_DM(-)
23 USB device negative data line.
USB_CNX
25 USB 5V Monitoring
!CONFIG
26 Active low. In normal mode, pull it low and hold for more than 8 seconds will
Vcc
27,28 Positive voltage supply voltage for the module (7-30VDC).
Description
reset the system to default settings. Pull it low upon power up will put the
module into recovery mode.
Table 3-6: JP3 Nano IP HV Option Pin-out
CONFIDENTIAL
In/
Out
O
I
O
O
I
I
O
O
O
O
I
O
O
I
O
I
I
I
I
31
