Microhard Systems Nano IP Series Operating Manual page 51

6.0 Configuration
If ‗static' is selected, the three following fields are to be manually populated
with values which will suit the network/devices to which the Nano IP Series
is connected.
If DHCP mode is If ‗DHCP' is selected, the three following fields will be automatically
selected, but there is no
populated by the DHCP server.
DHCP server available,
manually modified from the factory default value.
after the DHCP timeout
period the units will
default to function simply
as a 'wireless bridge'.
If DHCP is selected (see above), a unique IP address will be
assigned to the Nano IP Series; if STATIC IP address mode has
been selected, enter a suitable value for the specific network.
Within any IP network,
each device must have its
own unique IP address.
For a small private network with IP addresses appearing similar to
192.168.1.xx (Class C address), the standard 255.255.255.0
subnet mask may be applicable.
If DHCP mode is selected, the DHCP server will populate this field.
A SUBNET MASK is a bit
mask that separates the
network and host (device)
portions of an IP address.
If the Nano IP Series units are integrated into a network which has a
The ‗unmasked' portion
defined gateway, then, as with other hosts on the network, this gateway's
leaves available the
IP address will be entered into this field. If there is a DHCP server on the
information required to
network, and the IP Address Mode is selected to be DHCP, the DHCP
identify the various
server will populate this field with the appropriate gateway address.
devices on the subnet.
In a very small network (e.g. point-to-point, and STATIC IP Address Mode),
the gateway value is not critical. The IP address of the most significant
device on the overall network may be entered, or, if only two Nano IP
Series units are being used, make the gateway of IP Series No. 1 = IP
address of IP Series No. 2; gateway of IP Series No. 2 = IP address of IP
Series No. 1. The idea behind this approach is: If an IP Series at ‗one end'
of a wireless link receives a packet it is unsure where to send, send it to the
other end of the wireless link (i.e. the other IP Series) where it was quite
A GATEWAY is a point
likely destined.
within a network that acts
as an entrance to another
A simple way of looking at what the gateway value should be is: If a device
network.
has a packet of data is does not know where to send, send it to the
gateway. If necessary - and applicable - the gateway can forward the
In typical networks, a
packet onwards to another network.
router acts as a gateway.
© Microhard Systems Inc.
The DHCP Timeout value may be
CONFIDENTIAL
IP Address Mode
Values
static
dhcp
IP Address
Values
192.168.1.254
valid value is specific to
the network
Subnet Mask
Values
255.255.255.0
valid value is specific to
the network
IP Gateway
Values
192.168.1.1
valid value is specific to
the network
51
