6.0 Configuration
This setting applies to the Master only.
The default value is No, stating there are no Repeaters in the
network.
If there are 1 or more Repeaters in the network, configure this
With one or more
setting as Yes.
Repeaters in the system,
a network's throughput is
divided in half. Exercising
the option of back-to-back
‗Repeaters' - which
This setting applies to the Master only.
requires 2 Nano IP Series
at a ‗Repeater' site -
eliminates the division of
‗Balanced' is the default setting and is typically the best choice for
bandwidth.
‗Optimization'.
throughput is a priority) and Low Latency (best suited to small
If there is more than one
Repeater in a network,
packets).
the Repeaters should be
‗registered'. See
Optimization is a trade-off between throughput and latency.
‗Repeater Registration'
further along in this
section re how to
accomplish this.
This setting applies and will appear only if the Link Rate is set to
1.2Mbps.
Channel Number defines the number of channels the unit will hop
on. The minimum number is 4. (Digital Transmission System (DTS)
technology is applied at the 1.2Mbps link rate.)
(This setting does not apply if the Link Rate is 345kbps because of
the 64 channels that are available, the unit must hop on exactly 50 -
there is not option to either increase or decrease this amount.)
Zone restriction dictates within which band (zone) of frequencies that a particular unit will
operate.
Using zones simplifies network deployment by providing a convenient reference (e.g. Zone 1)
within which a given network can operate, thereby minimizing the potential for internetwork
interference. This is particularly useful when used in conjunction with Network Search Mode to
facilitate minimal interference among adjacently deployed networks.
The tables on the following page illustrate the various zones and their associated frequency
restrictions. Note that there is a difference between zone ‗values' depending on the Wireless
Link Rate selected. Currently Zone restriction is only supported on models with 345kpbs, and
1.2Mbps link rates available.
© Microhard Systems Inc.
The other options are High Throughput (when
CONFIDENTIAL
Repeater
Values
No
Yes
Optimization
Values
High Throughput
Balanced
Low Latency
Channel Number
Values
4-16
16
Zone Restriction
