Pin
Signal Description
1
Transmit Data +
2
Transmit Data –
3
Receive Data +
4
No Connect
Gigabit Ethernet Ports
Four RJ-45 Ethernet ports (NET 0, NET 1, NET 2, NET 3) can be accessed from the rear panel.
See
"Rear Panel Components" on page
Mbps, and 10000 Mbps.
Pin
Signal Description
1
Transmit/Receive Data 0 +
2
Transmit/Receive Data 0 –
3
Transmit/Receive Data 1 +
4
Transmit/Receive Data 2 +
Pin
Signal Description
5
No Connect
6
Receive Data –
7
No Connect
8
No Connect
13. The Ethernet interfaces operate at 100 Mbps, 1000
Pin
Signal Description
5
Transmit/Receive Data 2 –
6
Transmit/Receive Data 1 –
7
Transmit/Receive Data 3 +
8
Transmit/Receive Data 3 –
Powering On the Server for the First Time
Identifying Ports
57
