10 Gigabit Ethernet Ports

The server has four RJ-45 10-Gigabit Ethernet (10GbE) network connectors, labeled NET
3, NET 2, NET 1, and NET 0 on the rear panel. Use these ports to connect the server to the
network.
The LEDs located above each NET port are Link/Activity indicators for each port described in
this table.
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
Note -
one of these Ethernet ports. Refer to the Oracle ILOM Administor's Guide for Configuration
and Maintenance For Release 3.2.x at
instructions.
Pin
1
68 Netra SPARC S7-2 Server Installation Guide • January 2017
The Oracle ILOM sideband management feature enables you to access the SP using
Signal Description
Transmit/Receive Data 0 +
IEEE Terminology
100BASE-TX
1000BASE-T
10GBASE-T
http://www.oracle.com/goto/ilom321/docs
Pin
5
Transfer Rate
100 Mbits/sec
1000 Mbits/sec
10000 Mbits/sec
Signal Description
Transmit/Receive Data 2 -
for
