Identifying Ports
Pin
1
2
3
4
Related Information
"Rear Panel Components (Installation)" on page 20
■
"Connect the NET MGT Cable" on page 68
■
"Assign a Static IP Address to the NET MGT Port" on page 87
■
10 Gigabit Ethernet Ports
Four RJ-45 Ethernet ports (NET 0, NET 1, NET 2, NET 3) can be accessed from the rear panel.
See
"Rear Panel Components (Installation)" on page
Mbps, 1000 Mbps, and 10000 Mbps.
Pin
1
64
SPARC S7-2L Server Installation Guide • June 2017
Signal Description
Transmit Data +
Transmit Data –
Receive Data +
No Connect
Signal Description
Transmit/Receive Data 0 +
Pin
Signal Description
5
No Connect
6
Receive Data –
7
No Connect
8
No Connect
20. The Ethernet interfaces operate at 100
Pin
Signal Description
5
Transmit/Receive Data 2 –
